AudioSource 12 x 50W Digital Multi-Zone Power Amplifier - Manual

OWNER’S MANUAL
AD5012
AudioSource®
13970 SW 72nd Ave
Portland, OR 97223
503.914.4688
www.audiosource.net AD5012 Owner’s Manual 30117
Congratulations on your purchase of the AudioSource® AD5012.
Please take a few moments to read this entire manual, and be sure to
retain this document for future reference. Please read and observe all
safety instructions detailed on page 2.
NOTE: If any part of this product is damaged or missing, please call your
dealer or AudioSource® directly at 1.877.715.5439 or 503.914.4688.
Please read your warranty and retain your receipt and original carton
for possible future use.
For more information about AudioSource® electronics, speakers and
accessories please visit www.audiosource.net
FEATURES:
SPECIFICATIONS
Stereo (8 ohm): 12 x 50W per channel, <0.2% THD+N
Stereo (4 ohm): 12 x 75W per channel, <0.2% THD+N
Bridged Mono (8 ohm): 125W, 1kHz, <0.2% THD+N
Frequency Response: 20Hz ~ 20kHz, +/-0dB
Signal to Noise Ratio: 100dB below 50W output into 8 ohms
w/20kHz lowpass filter/A-Wgt
Channel Separation: 65dB @ 1kHz, referred to 50W output
into 8 ohms
Input Sensitivity: Variable, 430mV for full output with
Input Level control at maximum
AC Power Consumption: 1000W maximum
Net Weight: 34.5lbs / 15.6kgs
Gross Weight: 39.5lbs / 17.9kgs
Digital Multi-Zone Power Amplifier
AD5012
12 Channels (6 stereo zones)
12 Rear mounted level controls
12 Independent inputs, 2 Bus inputs, 1 optical input
Bus 1 and Bus 2 master level controls
Multi-function IR remote control
Normal, signal sensing, and trigger power modes
Rear mounted treble and bass controls for bus 1 & 2
Phoenix-style speaker connectors
LED status indicator lights
Bridgeable channel outputs
Rack mountable (rack mount included)
4.0”
(102mm)
16.63” (423mm)
14.75”
(375mm)
MULTI-ZONE POWER AMPLIFIER
AD5012
Input: 120/230V~, 60/50Hz, 1000W
