B360 Ambisonics Processor / User Guide
15
Displays
There are three display sections:
Input Meters
Displays the level of each channel of the input signal. The name of each channel is displayed below.
Range: Full scale, -infinity to 0 dBFS
Output Meters
Output display of the output B-format ambisonic stream.
Channels: W, X, Y, Z
Range: Full scale, -infinity to 0 dBFS
Peak indicator (beneath the output meters): Indicates the peak level of the loudest signal
Click on the indicator to clear the value.
Clipping indicator: Turns red when an output channel exceeds 0 dBFS.
Click on a clip light to clear it.
Sound Sphere
This display represents the channel’s imaging within the spherical Ambisonics soundscape as experienced from the
listening position. Small, color-coded globes indicate control settings.
