Features

Safety Instructions

Specifications

Product : Slim Portable Blu-ray/DVD Writer

Fold 1 :
4-panel
accordion

Fold 2 :
2-panel
accordion

Document : Combined

No : MFL67900080

Color Side 1: Black

Flat size : 50 x 25 cm

Color Side 2: Black

Finished size : 12.5 x 12.5 cm

Worldwide corporate site : http://www.LG.com

-40 °C to 60 °C

5 % to 90 % RH

5 °C to 45 °C

15 % to 85 %

Install the appropriate CD Recording Authoring Software before using this unit.

* Please uninstall any previous CD burning software you may have loaded on your PC in order to prevent possible compatibility

issues.

Once you have installed the application software, you may (if you wish) begin to reinstall previous software, taking note for errors.

We recommend using the drive with the latest software as some problems encountered when using the drive can be solved by

updating the software.

We recommend to use USBFast Software in Software Installation disc for better performance.

Software

• Universal Serial Bus (USB) 2.0 interface for high-speed data transfer.
• Ultra Slim Portable Blu-ray/DVD Writer
• Buffer Under Run error protection technology
• Emergency eject support
• Combination of CD-R/RW, DVD-R/RW, DVD+R/RW, DVD+R DL, DVD-R DL, DVD-RAM,
M-Disc(DVD+R SL, BD-R SL), BD-R(SL/DL/TL/QL, LTH) and BD-RE(SL/DL/TL)drive
functions into one drive.
• CD Family, DVD-ROM, BD-ROM read compatible.
• Supports BD 3D Movie Play.
• PC USB powered, no AC adapter needed.

System Environment

Computer

This unit can be operated in the system environment explained here.

• CPU : Pentium 2.4 GHz or higher

• O/S : Windows 8.1, 8 / 7 / Vista (32 bit, 64 bit), XP(SP3), Mac OS X v.10.7.5

or higher

• RAM : 1 GB or more

• HDD : 30 GB or more of available space (60 GB for Blu-ray Disc)

System

requirements

USB 2.0 (3.0 Compatible)

Interface

* Compatibility problem in write/read function may occur with some media depending on the media manufacturing quality.
* To achieve maximum Record & Write speed your system may require data to be copied first to the computer’s hard drive rather
than directly from another source disc or drive.
Blu-ray Disc movie playback
CPU: Following CPU recommended for playing Blu-ray Disc
-Intel: E6400 or higher
3D title playback: Intel Core 2 Duo E6750 (266GHz), AMD Phenom 9450 (2.1GHz) or higher.
Graphic Card: card with following GPU (Graphic Processing Unit) recommended.
-nVidia: GeForce 7600GTor higher/ GeForce 8400 or higher -ATI: ATI Radeon HD 2400 or higher
Graphic Card Driver shall meet AACS compliance criteria. Please consult your graphic card vendor for proper driver solution.
BD movies can be played only with HDMI or DVI Connection.

- For the sake of periodic improvements, the drive’s specifications and appearance are subject to change without prior notice.
- The maximum data transfer rate varies according to the performance capabilities of he PC.
- We have taken all possible measures to assure the quality of our products, but we cannot be responsible for the consequences
if defect occurs.

DVD-R :

Mitsubishi Kagaku Media, Verbatim.

DVD-RW :

JVC, Mitsubishi Kagaku Media.

DVD+R :

Mitsubishi Kagaku Media, Verbatim.

DVD+RW :

Mitsubishi Kagaku Media, Verbatim.

DVD±R DL :

Mitsubishi Kagaku Media, Verbatim.

DVD-RAM : Maxell,

Panasonic.

M-Disc (DVD+R SL) :

Millenniata

CD-R :

Mitsubishi Kagaku Media, Verbatim, Taiyo Yuden.

CD-RW :

LG, Mitsubishi Kagaku Media, Verbatim.

Recommended

media

manufacturer

BD-ROM : 250 ms typ.

DVD-ROM : 200 ms typ.

CD-ROM : 200 ms typ.

Storage

Environment

Operating

Environment

60,000 Power On Hours (Duty Cycle 10 %)
5 V DC

MTBF
Power Requirement

4 MB

Buffer capacity

Temperature
Humidity

BD-ROM(Single/Dual), BD-R(Single/Dual, LTH), BD-RE(Single/Dual),

BD-R/RE XL(3 Layer), DVD-ROM (Single/ Dual), DVD-RW, DVD-R,

DVD+RW, DVD+R, DVD+R Double layer, DVD-R Dual layer, DVD- RAM,

M-Disc(DVD+R SL, BD-R SL), CD-DA, CD-Extra, CD-ROM, CD-ROM XA,

CD-TEXT, CD-R, CD-RW, Photo-CD (Single & Multi-Session), Video CD,

DVD-VIDEO, BD-MV

CAUTION :

The laser used in the Writer can damage your eyes.

Do not attempt to open the cover. To reduce the risk of electric shock, do not remove
the cover (or back). There are no user-serviceable parts inside. Refer servicing to
qualified service personnel. Use of controls or performance of procedures other than
those specified herein may result in hazardous radiation exposure.

WARNING :

To reduce the risk of fire or electric shock, do not expose this

appliance to rain or moisture.

PERICOLO :

Il dispositivo di lettura e scrittura utilizzato in questo masterizzatore

utilizza un raggio laser che, se osservato da vicino, può danneggiare la vista. Evitare di

smontare il coperchio dell’apparecchio. Al fine di prevenire eventuali folgorazioni, evitare

di smontare l’apparecchio. All’interno dell’apparecchio non sono presenti parti che

richiedono manutenzione da parte dell’utente. In caso di difetti o guasti, rivolgersi ad un

Centro di Assistenza Tecnica. L’esecuzione di procedure diverse da quella espressamente

indicate in questo manuale può provocare pericolose esposizioni alle radiazioni laser.

ATTENZIONE :

Al fine di evitare cortocircuiti o principi di incendio, evitare di

esporre questo apparecchio alla pioggia o ad una eccessiva umidità ambientale.

ATTENTION :

Le faisceau laser utilisé dans ce graveur est dangereux pour les

yeux. Ne pas tenter d’ouvrir le couvercle. Ne déposer ni la façade, ni le panneau arrière
(risque d’électrocution). Aucun élément interne n’est réparable par l’utilisateur. L’utilisation
de commandes ainsi que l’exécution de procédures autres que celles spécifiées dans
le présent guide risque de provoquer une dangereuse exposition aux radiations.

AVERTISSEMENT :

Ne pas exposer ce matériel à la pluie ou à l’humidité

(risques d’incendie et d’électrocution).

VORSICHT :

Der in diesem Laufwerk benutzte Laser kann Ihre Augen schädigen.

Versuchen Sie keinesfalls, die Abdeckung zu öffnen. Um die Gefahr eines elektrischen
Schocks zu reduzieren, sollten Sie die Abdeckung (oder Rückseite) keinesfalls entfernen.
Im Inneren des Geräts befinden sich keine Teile, die vom Benutzer selbst gewartet
werden können. Überlassen Sie die Wartung qualifizierten Kundendiensttechnikern.
Beachten Sie bei der Benutzung von Bedienelementen und der Durchführung von
Prozeduren unbedingt die Anweisungen dieses Handbuchs, da andernfalls gefährliche
Strahlung freigesetzt werden kann.

WARNUNG :

Setzen Sie das Laufwerk keinesfalls Regen oder Feuchtigkeit aus,

um die Gefahr eines Brandes oder elektrischen Schocks zu reduzieren.

CUIDADO :

O laser utilizado no Gravador pode provocar danos nos seus olhos.

Não tente abrir a tampa. Para reduzir os riscos de choques eléctricos, não retire a
tampa (nem o painel posterior). Não existem peças ajustáveis pelo utilizador no interior
do aparelho. Solicite a assistência de pessoal qualificado para quaisquer trabalhos de
reparação. A utilização dos comandos ou a execução de procedimentos para além dos
especificados neste manual podem resultar numa exposição perigosa às radiações.

AVISO :

Para reduzir o risco de incêndio ou choque elétrico não exponha este

aparelho á chuva ou humidade.

PRECAUCION :

El láser utilizado en la unidad puede dañar sus ojos. No intente

abrir la tapa. Para reducir el riesgo de descarga eléctrica, no quite la tapa (ni la parte
posterior). No hay piezas internas que deba mantener el usuario. El servicio de
mantenimiento debe efectuarlo personal técnico cualificado. El uso de controles o la
ejecución de procedimientos distintos de los especificados en este manual pueden ser
causa de exposición a radiación peligrosa.

ADVERTENCIA :

Para reducir el riesgo de fuego o descarga eléctrica, no

exponga este aparato a la lluvia ni a la humedad.

CAUTION :

FCC COMPLIANCE STATEMENT

CLASS 3B VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND

INTERLOCKS DEFEATED.AVOID EXPOSURE TO THE BEAM.

This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:

ADVARSEL : KLASSE 3B SYNLIG OG USYNLIG LASERSTRÅLING I ÅBEN TILSTAND OG VED

AFBRUDTLÅSEFUNKTION. UNDGÅ ATBLIVE RAMTAF LASERSTRÅLEN.

VARO! : LUOKKA 3B AVATTAESSAJAKUMOTTAESSALUKITUS NÄKYVÄÄ JANÄKYMÄTÖNTÄ

LASERSÄTEILYÄ. VÄLTÄ LASERSÄTEILLE ALTISTUMISTA.

ATTENTION : CLASSE 3B RAYONNEMENTLASER VISIBLE ETINVISIBLE EN CAS D’OUVERTURE

ETENCLENCHEMENTS DEFECTUEUX, EVITER L'EXPOSITION AU FAISCEAU.

VORSICHT : SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG DER KLASSE 3B WENN

ABDECKUNG GEÖFFNETUND SICHERHEITSVERRIEGELUNG ÜBERBRÜCKTVERMEIDEN SIE

ES, SICH DEM STRAHLAUSZUSETZEN.

ADVARSEL : KLASSE 3B SYNLIG OG USYNLIG LASERSTRÅLING NÅR ÅPNES OG LÅS BRYTES.

UNNGÅ EKSPONERING FOR STRÅLEN.

VARNING : KLASS 3B SYNLIG OCH OSYNLIG LASERSTRÅLNING FÖREKOMMER NÄR OCH

MELLANLÅSETFÖRSTÖRS. UNDVIK EXPONERING UNDER STRÅLEN.

Microsoft and Windows are trademarks registered in the United States and other countries
by the Microsoft Corporation.

The company names and product names written in this manual are trademarks or registered
trademarks of the respective companies.

Please pay attention to handling Electrostatic Sensitive Devices, you may use anti-static
products such as wrist straps, heel straps, mats to protect your body from electrostatic.

Note :

- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an Authorized Service Center for help.

• FCC WARNING

Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.

• This product is for use only with UL listed personal computers that have installation
instructions detailing user-installation of card cage accessory.

EU Conformity Notice

LG Electronics hereby declares that this/these product(s) is/are

in compliance with the essential requirements and other relevant

provisions of Directive 2004/108/EC, 2006/95/EC, 2009/125/EC,

and 2011/65/EU.

European representative :

LG Electronics Inc. - EU Representative

Krijgsman 1, 1186 DM Amstelveen

The Netherlands

CLASS 1
LASER KLASSE 1
LUOKAN 1
KLASS 1
CLASE 1
CLASSE 1

LASER PRODUCT
PRODUKT
LASER LAITE
LASER APPARAT
PRODUCTO LÁSER
PRODOTTO LASER

Average Access

Time (

1/3

Stroke)

Caution:

System meeting the following requirements is needed in order to use USB 2.0 operation
with this drive.
• Computer that is equipped with a USB 2.0 – compliant USB connector or PCI adapter card,
and on which the USB 2.0 EHCI (Enhanced Host Controller Interface) driver software has
been installed. The USB 2.0 EHCI driver software is supplied with currently available PCI
adapter cards that conform to USB 2.0. Further, Microsoft has released the USB 2.0 EHCI
driver software for Windows XP, therefore it is also possible to use this driver software with
Windows XPSP3.
If you want to know in detail, please contact your USB 2.0 adapter dealer or consult your
PC manufacturer, or consult the Microsoft Corporation Web site.

General

Supported Discs

144 mm x 14.6 mm x 156 mm (5.7” x 0.6” x 6.1”)

Dimensions

(WxHxD)

About 270 g (0.6 Ibs)

Weight

USB 2.0 (3.0 Compatible)

Interface

Read/Write

Speed *³

Media
BD-ROM
BD-R

M-Disc (BD-R SL)
BD-RE

BDMV(AACS Compliant Disc)(SL/DL)
DVD-ROM
DVD-R

DVD+R

M-Disc (DVD+R SL)
DVD+RW
DVD-RW
DVD-RAM
DVD-Video(CSS Compliant Disc)(SL/DL)
CD-R
CD-RW
CD-ROM/CD-DA

Write :
-
2x, 4x, 6x
2x, 4x
2x, 4x, 6x
4x
2x / 2x
2x
-
-
2x, 4x, 8x
2x, 4x, 6x
2.4x, 4x, 8x
2.4x, 6x
4x
2.4x, 3.3x, 4x, 6x, 8x
2x, 3x, 4x, 6x
2x, 3x, 5x
-
10x, 16x, 24x
4x, 10x, 16x
-

Read :
6x max.
6x max.
6x max.
6x max.
6x max.
6x max.
4x max.
6x max.
8x max.
8x max.
8x max.
8x max.
8x max.
8x max.
8x max.
8x max.
5x max.
8x max.
24x max.
24x max.
24x max.

SL/DL
SL/DL
TL/QL(4 Layer)
SL LTH

SL/DL
TL

SL/DL
SL
DL
SL
DL

Features

Safety Instructions

Specifications

Product : Slim Portable Blu-ray/DVD Writer

Fold 1 :
4-panel
accordion

Fold 2 :
2-panel
accordion

Document : Combined

No : MFL67900080

Color Side 1: Black

Flat size : 50 x 25 cm

Color Side 2: Black

Finished size : 12.5 x 12.5 cm

Worldwide corporate site : http://www.LG.com

-40 °C to 60 °C

5 % to 90 % RH

5 °C to 45 °C

15 % to 85 %

Install the appropriate CD Recording Authoring Software before using this unit.

* Please uninstall any previous CD burning software you may have loaded on your PC in order to prevent possible compatibility

issues.

Once you have installed the application software, you may (if you wish) begin to reinstall previous software, taking note for errors.

We recommend using the drive with the latest software as some problems encountered when using the drive can be solved by

updating the software.

We recommend to use USBFast Software in Software Installation disc for better performance.

Software

System Environment

Computer

This unit can be operated in the system environment explained here.

• CPU : Pentium 2.4 GHz or higher

• O/S : Windows 8.1, 8 / 7 / Vista (32 bit, 64 bit), XP(SP3), Mac OS X v.10.7.5

or higher

• RAM : 1 GB or more

• HDD : 30 GB or more of available space (60 GB for Blu-ray Disc)

System

requirements

USB 2.0 (3.0 Compatible)

Interface

DVD-R :

Mitsubishi Kagaku Media, Verbatim.

DVD-RW :

JVC, Mitsubishi Kagaku Media.

DVD+R :

Mitsubishi Kagaku Media, Verbatim.

DVD+RW :

Mitsubishi Kagaku Media, Verbatim.

DVD±R DL :

Mitsubishi Kagaku Media, Verbatim.

DVD-RAM : Maxell,

Panasonic.

M-Disc (DVD+R SL) :

Millenniata

CD-R :

Mitsubishi Kagaku Media, Verbatim, Taiyo Yuden.

CD-RW :

LG, Mitsubishi Kagaku Media, Verbatim.

Recommended

media

manufacturer

BD-ROM : 250 ms typ.

DVD-ROM : 200 ms typ.

CD-ROM : 200 ms typ.

Storage

Environment

Operating

Environment

60,000 Power On Hours (Duty Cycle 10 %)
5 V DC

MTBF
Power Requirement

4 MB

Buffer capacity

Temperature
Humidity

BD-ROM(Single/Dual), BD-R(Single/Dual, LTH), BD-RE(Single/Dual),

BD-R/RE XL(3 Layer), DVD-ROM (Single/ Dual), DVD-RW, DVD-R,

DVD+RW, DVD+R, DVD+R Double layer, DVD-R Dual layer, DVD- RAM,

M-Disc(DVD+R SL, BD-R SL), CD-DA, CD-Extra, CD-ROM, CD-ROM XA,

CD-TEXT, CD-R, CD-RW, Photo-CD (Single & Multi-Session), Video CD,

DVD-VIDEO, BD-MV

CAUTION :

The laser used in the Writer can damage your eyes.

WARNING :

To reduce the risk of fire or electric shock, do not expose this

appliance to rain or moisture.

PERICOLO :

Il dispositivo di lettura e scrittura utilizzato in questo masterizzatore

utilizza un raggio laser che, se osservato da vicino, può danneggiare la vista. Evitare di

smontare il coperchio dell’apparecchio. Al fine di prevenire eventuali folgorazioni, evitare

di smontare l’apparecchio. All’interno dell’apparecchio non sono presenti parti che

richiedono manutenzione da parte dell’utente. In caso di difetti o guasti, rivolgersi ad un

Centro di Assistenza Tecnica. L’esecuzione di procedure diverse da quella espressamente

indicate in questo manuale può provocare pericolose esposizioni alle radiazioni laser.

ATTENZIONE :

Al fine di evitare cortocircuiti o principi di incendio, evitare di

esporre questo apparecchio alla pioggia o ad una eccessiva umidità ambientale.

ATTENTION :

Le faisceau laser utilisé dans ce graveur est dangereux pour les

AVERTISSEMENT :

Ne pas exposer ce matériel à la pluie ou à l’humidité

(risques d’incendie et d’électrocution).

VORSICHT :

Der in diesem Laufwerk benutzte Laser kann Ihre Augen schädigen.

WARNUNG :

Setzen Sie das Laufwerk keinesfalls Regen oder Feuchtigkeit aus,

um die Gefahr eines Brandes oder elektrischen Schocks zu reduzieren.

CUIDADO :

O laser utilizado no Gravador pode provocar danos nos seus olhos.

AVISO :

Para reduzir o risco de incêndio ou choque elétrico não exponha este

aparelho á chuva ou humidade.

PRECAUCION :

El láser utilizado en la unidad puede dañar sus ojos. No intente

ADVERTENCIA :

Para reducir el riesgo de fuego o descarga eléctrica, no

exponga este aparato a la lluvia ni a la humedad.

CAUTION :

FCC COMPLIANCE STATEMENT

CLASS 3B VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND

INTERLOCKS DEFEATED.AVOID EXPOSURE TO THE BEAM.

ADVARSEL : KLASSE 3B SYNLIG OG USYNLIG LASERSTRÅLING I ÅBEN TILSTAND OG VED

AFBRUDTLÅSEFUNKTION. UNDGÅ ATBLIVE RAMTAF LASERSTRÅLEN.

VARO! : LUOKKA 3B AVATTAESSAJAKUMOTTAESSALUKITUS NÄKYVÄÄ JANÄKYMÄTÖNTÄ

LASERSÄTEILYÄ. VÄLTÄ LASERSÄTEILLE ALTISTUMISTA.

ATTENTION : CLASSE 3B RAYONNEMENTLASER VISIBLE ETINVISIBLE EN CAS D’OUVERTURE

ETENCLENCHEMENTS DEFECTUEUX, EVITER L'EXPOSITION AU FAISCEAU.

VORSICHT : SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG DER KLASSE 3B WENN

ABDECKUNG GEÖFFNETUND SICHERHEITSVERRIEGELUNG ÜBERBRÜCKTVERMEIDEN SIE

ES, SICH DEM STRAHLAUSZUSETZEN.

ADVARSEL : KLASSE 3B SYNLIG OG USYNLIG LASERSTRÅLING NÅR ÅPNES OG LÅS BRYTES.

UNNGÅ EKSPONERING FOR STRÅLEN.

VARNING : KLASS 3B SYNLIG OCH OSYNLIG LASERSTRÅLNING FÖREKOMMER NÄR OCH

MELLANLÅSETFÖRSTÖRS. UNDVIK EXPONERING UNDER STRÅLEN.

Microsoft and Windows are trademarks registered in the United States and other countries
by the Microsoft Corporation.

The company names and product names written in this manual are trademarks or registered
trademarks of the respective companies.

Please pay attention to handling Electrostatic Sensitive Devices, you may use anti-static
products such as wrist straps, heel straps, mats to protect your body from electrostatic.

Note :

• FCC WARNING

Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.

• This product is for use only with UL listed personal computers that have installation
instructions detailing user-installation of card cage accessory.

EU Conformity Notice

LG Electronics hereby declares that this/these product(s) is/are

in compliance with the essential requirements and other relevant

provisions of Directive 2004/108/EC, 2006/95/EC, 2009/125/EC,

and 2011/65/EU.

European representative :

LG Electronics Inc. - EU Representative

Krijgsman 1, 1186 DM Amstelveen

The Netherlands

CLASS 1
LASER KLASSE 1
LUOKAN 1
KLASS 1
CLASE 1
CLASSE 1

LASER PRODUCT
PRODUKT
LASER LAITE
LASER APPARAT
PRODUCTO LÁSER
PRODOTTO LASER

Average Access

Time (

1/3

Stroke)

Caution:

General

Supported Discs

144 mm x 14.6 mm x 156 mm (5.7” x 0.6” x 6.1”)

Dimensions

(WxHxD)

About 270 g (0.6 Ibs)

Weight

USB 2.0 (3.0 Compatible)

Interface

Read/Write

Speed *³

Media
BD-ROM
BD-R

M-Disc (BD-R SL)
BD-RE

BDMV(AACS Compliant Disc)(SL/DL)
DVD-ROM
DVD-R

DVD+R

M-Disc (DVD+R SL)
DVD+RW
DVD-RW
DVD-RAM
DVD-Video(CSS Compliant Disc)(SL/DL)
CD-R
CD-RW
CD-ROM/CD-DA

Write :
-
2x, 4x, 6x
2x, 4x
2x, 4x, 6x
4x
2x / 2x
2x
-
-
2x, 4x, 8x
2x, 4x, 6x
2.4x, 4x, 8x
2.4x, 6x
4x
2.4x, 3.3x, 4x, 6x, 8x
2x, 3x, 4x, 6x
2x, 3x, 5x
-
10x, 16x, 24x
4x, 10x, 16x
-

Read :
6x max.
6x max.
6x max.
6x max.
6x max.
6x max.
4x max.
6x max.
8x max.
8x max.
8x max.
8x max.
8x max.
8x max.
8x max.
8x max.
5x max.
8x max.
24x max.
24x max.
24x max.

SL/DL
SL/DL
TL/QL(4 Layer)
SL LTH

SL/DL
TL

SL/DL
SL
DL
SL
DL

* Initial installation of Tool CD requires internet access for Windows Vista users.

• CPU : Pentium 2.4 GHz or higher

• O/S : Windows 10 / 8.1 / 8 / 7 / Vista (32 bit, 64 bit) / XP(SP3),

Mac OS X v.10.7.5 or higher

• RAM : 1 GB or more

• HDD : 30 GB or more of available space (60 GB for Blu-ray Disc)

Features

Safety Instructions

Specifications

Product : Slim Portable Blu-ray/DVD Writer

Fold 1 :
4-panel
accordion

Fold 2 :
2-panel
accordion

Document : Combined

No : MFL67900080

Color Side 1: Black

Flat size : 50 x 25 cm

Color Side 2: Black

Finished size : 12.5 x 12.5 cm

Worldwide corporate site : http://www.LG.com

-40 °C to 60 °C

5 % to 90 % RH

5 °C to 45 °C

15 % to 85 %

Install the appropriate CD Recording Authoring Software before using this unit.

* Please uninstall any previous CD burning software you may have loaded on your PC in order to prevent possible compatibility

issues.

Once you have installed the application software, you may (if you wish) begin to reinstall previous software, taking note for errors.

We recommend using the drive with the latest software as some problems encountered when using the drive can be solved by

updating the software.

We recommend to use USBFast Software in Software Installation disc for better performance.

Software

System Environment

Computer

This unit can be operated in the system environment explained here.

• CPU : Pentium 2.4 GHz or higher

• O/S : Windows 8.1, 8 / 7 / Vista (32 bit, 64 bit), XP(SP3), Mac OS X v.10.7.5

or higher

• RAM : 1 GB or more

• HDD : 30 GB or more of available space (60 GB for Blu-ray Disc)

System

requirements

USB 2.0 (3.0 Compatible)

Interface

DVD-R :

Mitsubishi Kagaku Media, Verbatim.

DVD-RW :

JVC, Mitsubishi Kagaku Media.

DVD+R :

Mitsubishi Kagaku Media, Verbatim.

DVD+RW :

Mitsubishi Kagaku Media, Verbatim.

DVD±R DL :

Mitsubishi Kagaku Media, Verbatim.

DVD-RAM : Maxell,

Panasonic.

M-Disc (DVD+R SL) :

Millenniata

CD-R :

Mitsubishi Kagaku Media, Verbatim, Taiyo Yuden.

CD-RW :

LG, Mitsubishi Kagaku Media, Verbatim.

Recommended

media

manufacturer

BD-ROM : 250 ms typ.

DVD-ROM : 200 ms typ.

CD-ROM : 200 ms typ.

Storage

Environment

Operating

Environment

60,000 Power On Hours (Duty Cycle 10 %)
5 V DC

MTBF
Power Requirement

4 MB

Buffer capacity

Temperature
Humidity

BD-ROM(Single/Dual), BD-R(Single/Dual, LTH), BD-RE(Single/Dual),

BD-R/RE XL(3 Layer), DVD-ROM (Single/ Dual), DVD-RW, DVD-R,

DVD+RW, DVD+R, DVD+R Double layer, DVD-R Dual layer, DVD- RAM,

M-Disc(DVD+R SL, BD-R SL), CD-DA, CD-Extra, CD-ROM, CD-ROM XA,

CD-TEXT, CD-R, CD-RW, Photo-CD (Single & Multi-Session), Video CD,

DVD-VIDEO, BD-MV

CAUTION :

The laser used in the Writer can damage your eyes.

WARNING :

To reduce the risk of fire or electric shock, do not expose this

appliance to rain or moisture.

PERICOLO :

Il dispositivo di lettura e scrittura utilizzato in questo masterizzatore

utilizza un raggio laser che, se osservato da vicino, può danneggiare la vista. Evitare di

smontare il coperchio dell’apparecchio. Al fine di prevenire eventuali folgorazioni, evitare

di smontare l’apparecchio. All’interno dell’apparecchio non sono presenti parti che

richiedono manutenzione da parte dell’utente. In caso di difetti o guasti, rivolgersi ad un

Centro di Assistenza Tecnica. L’esecuzione di procedure diverse da quella espressamente

indicate in questo manuale può provocare pericolose esposizioni alle radiazioni laser.

ATTENZIONE :

Al fine di evitare cortocircuiti o principi di incendio, evitare di

esporre questo apparecchio alla pioggia o ad una eccessiva umidità ambientale.

ATTENTION :

Le faisceau laser utilisé dans ce graveur est dangereux pour les

AVERTISSEMENT :

Ne pas exposer ce matériel à la pluie ou à l’humidité

(risques d’incendie et d’électrocution).

VORSICHT :

Der in diesem Laufwerk benutzte Laser kann Ihre Augen schädigen.

WARNUNG :

Setzen Sie das Laufwerk keinesfalls Regen oder Feuchtigkeit aus,

um die Gefahr eines Brandes oder elektrischen Schocks zu reduzieren.

CUIDADO :

O laser utilizado no Gravador pode provocar danos nos seus olhos.

AVISO :

Para reduzir o risco de incêndio ou choque elétrico não exponha este

aparelho á chuva ou humidade.

PRECAUCION :

El láser utilizado en la unidad puede dañar sus ojos. No intente

ADVERTENCIA :

Para reducir el riesgo de fuego o descarga eléctrica, no

exponga este aparato a la lluvia ni a la humedad.

CAUTION :

FCC COMPLIANCE STATEMENT

CLASS 3B VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND

INTERLOCKS DEFEATED.AVOID EXPOSURE TO THE BEAM.

ADVARSEL : KLASSE 3B SYNLIG OG USYNLIG LASERSTRÅLING I ÅBEN TILSTAND OG VED

AFBRUDTLÅSEFUNKTION. UNDGÅ ATBLIVE RAMTAF LASERSTRÅLEN.

VARO! : LUOKKA 3B AVATTAESSAJAKUMOTTAESSALUKITUS NÄKYVÄÄ JANÄKYMÄTÖNTÄ

LASERSÄTEILYÄ. VÄLTÄ LASERSÄTEILLE ALTISTUMISTA.

ATTENTION : CLASSE 3B RAYONNEMENTLASER VISIBLE ETINVISIBLE EN CAS D’OUVERTURE

ETENCLENCHEMENTS DEFECTUEUX, EVITER L'EXPOSITION AU FAISCEAU.

VORSICHT : SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG DER KLASSE 3B WENN

ABDECKUNG GEÖFFNETUND SICHERHEITSVERRIEGELUNG ÜBERBRÜCKTVERMEIDEN SIE

ES, SICH DEM STRAHLAUSZUSETZEN.

ADVARSEL : KLASSE 3B SYNLIG OG USYNLIG LASERSTRÅLING NÅR ÅPNES OG LÅS BRYTES.

UNNGÅ EKSPONERING FOR STRÅLEN.

VARNING : KLASS 3B SYNLIG OCH OSYNLIG LASERSTRÅLNING FÖREKOMMER NÄR OCH

MELLANLÅSETFÖRSTÖRS. UNDVIK EXPONERING UNDER STRÅLEN.

Microsoft and Windows are trademarks registered in the United States and other countries
by the Microsoft Corporation.

The company names and product names written in this manual are trademarks or registered
trademarks of the respective companies.

Please pay attention to handling Electrostatic Sensitive Devices, you may use anti-static
products such as wrist straps, heel straps, mats to protect your body from electrostatic.

Note :

• FCC WARNING

Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.

• This product is for use only with UL listed personal computers that have installation
instructions detailing user-installation of card cage accessory.

EU Conformity Notice

LG Electronics hereby declares that this/these product(s) is/are

in compliance with the essential requirements and other relevant

provisions of Directive 2004/108/EC, 2006/95/EC, 2009/125/EC,

and 2011/65/EU.

European representative :

LG Electronics Inc. - EU Representative

Krijgsman 1, 1186 DM Amstelveen

The Netherlands

CLASS 1
LASER KLASSE 1
LUOKAN 1
KLASS 1
CLASE 1
CLASSE 1

LASER PRODUCT
PRODUKT
LASER LAITE
LASER APPARAT
PRODUCTO LÁSER
PRODOTTO LASER

Average Access

Time (

1/3

Stroke)

Caution:

General

Supported Discs

144 mm x 14.6 mm x 156 mm (5.7” x 0.6” x 6.1”)

Dimensions

(WxHxD)

About 270 g (0.6 Ibs)

Weight

USB 2.0 (3.0 Compatible)

Interface

Read/Write

Speed *³

Media
BD-ROM
BD-R

M-Disc (BD-R SL)
BD-RE

BDMV(AACS Compliant Disc)(SL/DL)
DVD-ROM
DVD-R

DVD+R

M-Disc (DVD+R SL)
DVD+RW
DVD-RW
DVD-RAM
DVD-Video(CSS Compliant Disc)(SL/DL)
CD-R
CD-RW
CD-ROM/CD-DA

Write :
-
2x, 4x, 6x
2x, 4x
2x, 4x, 6x
4x
2x / 2x
2x
-
-
2x, 4x, 8x
2x, 4x, 6x
2.4x, 4x, 8x
2.4x, 6x
4x
2.4x, 3.3x, 4x, 6x, 8x
2x, 3x, 4x, 6x
2x, 3x, 5x
-
10x, 16x, 24x
4x, 10x, 16x
-

Read :
6x max.
6x max.
6x max.
6x max.
6x max.
6x max.
4x max.
6x max.
8x max.
8x max.
8x max.
8x max.
8x max.
8x max.
8x max.
8x max.
5x max.
8x max.
24x max.
24x max.
24x max.

SL/DL
SL/DL
TL/QL(4 Layer)
SL LTH

SL/DL
TL

SL/DL
SL
DL
SL
DL



Microsoft

and Windows

are trademarks registered in the United States and other countries by the

Microsoft Corporation.



The company names and product names written in this manual are trademarks or registered

trademarks of the respective companies.



Please pay attention to handling Electrostatic Sensitive Devices, you may use anti-static products

such as wrist straps, heel straps, mats to protect your body from electrostatic.

Declaration of Conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions :

(1) this device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

Model : WP50NB40

Responsible Party : Hitachi-LG Data Storage, Austin FA Center

Address : 11801 Stonehollow Dr. Suite 125 Austin, TX 78758

Telephone Number : (512) 832-8082

Advertising
