CONTENTS
Images Part Name Amount Usage
HDDcage 1 Installationofharddisk
HDDrubberdecoupling 4 DecoupledmountingofHDD
6#32 screw 12
Affixingthemotherboard
andPSUbracket
M3 screw 12 FasteningtheSSD
HDDscrew 12 AffixingtheHDD
Velcroties 6 Cablemanagement
EXPLODED VIEW AND DESCRIPTION OF PARTS
A Sidepanel H Detachabletopbracketforfansandradiators
B PureWings2fan I PSUbracket
C Bottomdustfilter J Interchangeable top covers
D Interchangeable front panels K PSUshroud
E Frontdustfilter L TopcoverofPSUshroud
F DoubleHDDcage M HDDslotcover*
G SSDbracket
J
A
M
G
B
H G
F
B
I
L
A
K
E
D
C
*SilentBase802Window
