- 8 -
2-2 Product Specifications
CPU Š LGA1700 socket: Support for the 13th and 12th Generation Intel ® Core ™ , Pentium ®
Gold and Celeron ® Processors
(Go to GIGABYTE's website for the latest CPU support list.)
Š L3 cache varies with CPU
Chipset Š Intel ® Z790 Express Chipset
Memory Š Support for DDR5 5600/5200/4800/4400 MHz memory modules
jkl
Š Support for DDR4 3200/3000/2933/2666/2400/2133 MHz memory modules
m
Š 4 x DDR DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)
of system memory
Š Dual channel memory architecture
Š Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in
non-ECC mode)
Š Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Š Support for Extreme Memory Profile (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
Š Integrated Graphics Processor-Intel ® HD Graphics support:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.0 version and HDCP 2.3.
- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
jkl
* Support for DisplayPort 1.2 version and HDCP 2.3
(Graphics specifications may vary depending on CPU support.)
Audio Š Realtek ® Audio CODEC
Š High Definition Audio
Š 2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To configure
7.1-channel audio, access the audio software for audio settings.
Š Support for S/PDIF Out
LAN Š Realtek ® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Wireless
Communication
Module
j
Š Intel ® Wi-Fi 6E AX210
- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.3
- Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
(Actual data rate may vary depending on environment and equipment.)
Wireless
Communication
Module
k
Š Realtek ® Wi-Fi RTL8821CE
- WIFI 802.11a, b, g, n, ac, supporting 2.4/5 GHz Dual-Band
- BLUETOOTH 4.2
- Support for 11ac wireless standard and up to 433 Mbps data rate
(Actual data rate may vary depending on environment and equipment.)
j
Only for Z790 UD AX.
k
Only for Z790 UD AC.
l
Only for Z790 UD.
m
Only for Z790 D DDR4.
