Safety Information Specifications
Specifications
CPU
Supports 1st, 2nd and 3rd Gen AMD Ryzen™/ Ryzen™ with
Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with
Radeon™ Graphics/ Athlon™ with Radeon™ Vega Graphics
Desktop Processors for Socket AM4
Chipset AMD ® B450 chipset
Memory
y
4x DDR4 memory slots, support up to 64GB*
ƒ Supports 1866/ 2133/ 2400/ 2667Mhz (by JEDEC)
ƒ Supports 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz
(by A-XMP OC MODE)
y Dual channel memory architecture
y Supports ECC UDIMM memory (non-ECC mode)
y Support non-ECC UDIMM memory
* Please refer www.msi.com for more information on
compatible memory.
Expansion Slots
y
1x PCIe 3.0 x16 slot
ƒ 1st, 2nd and 3rd Gen AMD Ryzen™ support x16 mode
ƒ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD
Ryzen™ with Radeon™ Graphics support x8 mode
ƒ Athlon™ with Radeon™ Vega Graphics support x4 mode
y
2x PCIe 2.0 x1 slots
Onboard
Graphics
y 1x VGA port, supports a maximum resolution of
2048x1280@60Hz, 1920x1200@60Hz*
y
1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz*
y
1x HDMI™ 1.4 port, supports a maximum resolution of
4096x2160 @30Hz, 2560x1600 @60Hz*
* Only support when using Ryzen™ with Radeon™ Vega
Graphics, 2nd Gen AMD Ryzen™ with Radeon™ Graphics and
Athlon™ with Radeon™ Vega Graphics processors
* Maximum shared memory of 2048 MB
Storage
AMD ® B450 Chipset
y 4x SATA 6Gb/s ports
ƒ Supports RAID 0, RAID1 and RAID 10
y
1x M.2 slot (Key M)
ƒ Supports PCIe 3.0 x4 (1st, 2nd and 3rd Gen AMD
Ryzen™/ Ryzen™ with Radeon™ Vega Graphics and 2nd
Gen AMD Ryzen™ with Radeon™ Graphics) or PCIe 3.0 x2
(Athlon™ with Radeon™ Vega Graphics) and SATA 6Gb/s
ƒ Supports 2242/ 2260 /2280 storage devices
Continued on next page
