WEB BROWSER-BASED CONFIGURATION
146
know its IP address. You can find the IP address assigned by
the ArcHTTP proxy server installation: Binding IP:[X.X.X.X] and
controller listen port.
1. You can click on the individual adapter icon located on left
column of the “ArcHTTP Configurations” screen or Launch
your McRAID storage manager by entering http://[Computer
IP Address]:[Port Number] in the web browser.
2. When connection is established, the "System Login" screen
appears. The SAS RAID controller default user name is
“admin” and the password is “0000”.
• Start-up from Ethernet Port (Out-of-Band)
The SAS RAID controller also offers an alternative out-of-band
method for McRAID storage manager. User can access the built-
in configuration without running the ArcHttp proxy server on
the host system. The web browser-based McRAID storage
manager is a HTML-based application, which utilizes the brows-
er installed on your remote system. To ensure proper commu-
nications between the SAS RAID controller and McRAID storage
manager, please connect the SAS RAID controller LAN port to
any LAN switch port.
The RAID storage has embedded the TCP/IP & web browser-
based McRAID storage manager in the firmware. User can re-
mote manage the SAS RAID controller without adding any user
specific software (platform independent) via standard web
browsers directly connected to the 10/100Mbit RJ45 LAN port.
To configure SAS RAID controller on a remote machine, you
need to know its IP address. The IP address is default shown on
the LCD initial start-up screen. Launch your McRAID storage
manager by entering http://[IP Address] in the web browser.
Note:
You can find controller Ethernet port IP address in McBIOS
RAID manager “System Information” option.
