BIOS CONFIGURATION
79
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Volume Set Function
Volume Set Functions
Create Volume Set
Create Raid30/50/60
Delete Volume Set
Modify Volume Set
Check Volume Set
Stop Volume Check
Display Volume Info. Display Volume Info.
Select Volume To Display
ARC-1880-VOL#009 (Raid 30/50/60 Vol)
VOL#003R30Vo14-1(Raid Set # 002)
VOL#003R30Vo14-2(Raid Set # 003)
VOL#003R30Vo14-3(Raid Set # 004)
ARC-1880-VOL#004 (Raid 30/50/60 Vol)
The Volume Set Information
Volume Set Name : ARC-1883-VOL # 004
Raid Set Name : Raid Set # 02
Volume Capacity : 1200.0GB
Volume State : Migration
SCSI CH/ID/Lun : 0/0/4
Raid Level : 5
Stripe Size : 64K
Block Size : 512 Bytes
Member Disk : 5
Cache Attribute : Write-Back
Write Protect : Disabled
Tag Queuing : Enabled
3.7.4 Physical Drives
Choose this option from the main menu to select a physical disk
and perform the operations listed above. Move the cursor bar to
an item, then press Enter key to select the desired function.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Physical Drives
