www.PyleUSA.com 8 9 www.PyleUSA.com
Problem
No Power
"Ensure the power cord is securely connected.
*Plug a different device into the electrical outlet to
verify that the outlet is working correctly
No Sound
*The wrong input was selected on the amplifier
*Music master volume control is set to minimum
• Fuse defective
*Speakers and speaker cables are either not
connected, loose or malfunctioning.
Microphone No Sound
*The microphone is not turned on
*The microphone cable is either loose or not
functioning
*The microphone volume for that channel is set to
minimum
*The microphone is not functioning correctly
Severe Hum or Noise
*Ensure all cables and wires are securely
connected
*Connect a different source device to see if the
buzzing persists. If does not, the problem may be
with the original device.
• Connect your device to a different input to the
amplifier
• The volume is set too high and the loudspeakers
distort
Help & Troubleshooting
If you experience any of the following difficulties while using the unit, use this
troubleshooting guide to help you remedy the problem, should any problem
persist, consult your nearest dealer.
Features:
• 2-Channel Pro Audio Amplifier
• Bridge able Amp: Bridge Mode Ability
• Built-in Wireless BT Streaming
• (2) 1/4" TRS Input Connector Jacks
• (2) XLR Input Connector Jacks
• (3) SpeakOn Output Connectors (AlB/Bridged)
• (2) Pair Speaker Terminal Binding Post Connectors
• Power, Protect, Clip, Signal LED Indicators
• Left and Right Channel Level Signal Indicators
• Built-in Ventilation Cooling Fans
• Front Panel Control Center
• Rack-Mountable System
Wireless BT Connectivity:
• Simple & Hassle-Free Pairing
• Instant Wireless Audio Streaming Ability
• Works with All of Today's Latest Wireless BT Devices
• Wireless BT Network Name: '
PYLE PRO '
• Wireless BT Version: 5.0
• Wireless Range: Up to 30'+ ft.
What's in the Box:
• Pro Audio Amplifier • Power Cable • BT and FM Antenna
Technical Specs:
• Power Output: 2000 Watt MAX
• Amplifier Type: 2-Channel
• 2x 1000 Watt @ 4 0hm
• 2x 500 Watt @ 8 0hm
• Distortion: <1.0%
• Input Level: + 4dB
• Signal/Noise Ratio: 102dB
• Frequency Response: 20Hz - 20kHz, +/- 0.2dB
• Power Supply: 120/220V, Switchable
• Dimensions (L x W x H): 19.09" x 9.84" x 3.54" -inches
This products can expose you to a chemical or group of chemicals, which
may include ”Lead (Pb)” which is known in the state of California to cause
cancer, birth defects, or other reproductive harm. For more info, go to
https://www.p65warnings.ca.gov/ .
