When necessary | Specifications
46 En
Wireless Network
Wireless Network Standards . . . . . . . . . . . . . . . . IEEE 802.11 a/b/g/n/ac*
* 20 MHz channel bandwidth only
Radio Frequency Band . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4 GHz, 5 GHz
WPS (Wi-Fi Protected Setup)
PIN method
Available Security Method
WEP
WPA2-PSK (AES)
Mixed Mode
Audio section (Network, Bluetooth)
Output level (1 kHz, 0 dB, Fs 44.1 kHz) . . . . . . . . . . . . . . . . . . 2.0 ±0.3 V
Signal to Noise Ratio (IHF-A Network) (Infinity zero, Fs 44.1 kHz)
. . . . . . . . . . . . . . . . . . .110 dB or higher
Dynamic range (1 kHz, –60 dB, Fs 44.1 kHz) . . . . . . . . . .100 dB or higher
Harmonic Distortion (1 kHz, 0 dB, Fs 44.1 kHz) . . . . . . . . 0.003% or lower
Frequency Response
Fs 44.1 kHz . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Hz–20 kHz (+0/–3 dB)
Fs 48 kHz . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Hz–24 kHz (+0/–3 dB)
Fs 96 kHz . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Hz–48 kHz (+0/–3 dB)
Fs 192 kHz . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Hz–96 kHz (+0/–6 dB)
Audio section (PHONO)
Output level
PHONO OUT (1 kHz, 3.54 cm/sec) . . . . . . . . . . . . . . . 2.5 mV ±3 dBV
LINE OUT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .450 mV (–7 dBV)
Signal to Noise Ratio (A-weighted, 20 kHz LPF) . . . . . . . . .67 dB or higher
General
AC adaptor power supply
Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AC 100-240 V 50/60 Hz
Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 V 1 A
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 W
Eco standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.3 W
Network Standby On/Bluetooth Standby Off
Wired . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.4 W
Wireless (Wi-Fi) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.8 W
Network Standby On/Bluetooth Standby On
Wired . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.6 W
Wireless (Wi-Fi) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.8 W
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.7 kg / 12.6 lbs
Dimensions (width × height × depth)
. . . . . . . . . . . . . . . . . . . . 450 Ч 136 Ч 368 mm / 17-3/4" Ч 5-3/8" Ч 14-1/2"
(including legs and protrusions)
 The contents of this manual apply to the latest specifications as of the
publishing date. To obtain the latest manual, access the Yamaha website
then download the manual file.
