7
Managing Tracks
Track Playback
To listen to recorded tracks, select FILE LIST from the menu
screen. Highlight a track and select PLAYBACK to open it.
Playback Controls
Function Joystick action
Previous / next track Press left / right
Rewind / fast forward Hold left / right
Play / pause Center push
Return to track list Press left while paused
Return to home screen Press record button
Deleting Tracks
To delete audio tracks, select FILE LIST from the menu screen and open
the track you would like to delete, and select DELETE .
Note: Once tracks have been deleted, they cannot be recovered.
Utilities
Exporting Tracks
To export .WAV audio files, turn the device off and remove the MicroSD
memory card. Transfer files to a computer using an SD card adapter or
USB adapter. All imported tracks include a title and timestamp.
Tip: For best performance, format the memory card in the device every time after
exporting tracks.
SD CARD
Remaining recording time is displayed and the
following settings can be accessed:
FORMAT CARD : Formatting the microSD card will erase
all data and should be done before first use.
MAX FILE TIME : Adjusting the maximum file size
determines the partitioning of longer tracks. If the
maximum file size is set to 1GB (2 hours), a 6 hour
recording will be divided into three separate WAV
files.
SET FILE NAME : The file name is set to TRACK by
default, but can be changed by selecting a character
and scrolling up or down to change it. This feature is
useful for identifying different sessions or projects.
BACKLIGHT
Adjusts the duration that the LED screen
backlight will remain on.
TIME/DATE
Set the time and date so that tracks include a
timestamp when exported.
BATTERY TYPE
Select the appropriate battery type for the meter
to read accurately.
CAMERA OUT
Adjusts the volume of the audio signal that is
sent to the camera.
HIGH (0 dB) : For cameras with a low-gain preamp.
MEDIUM (-20 dB) : Appropriate for most cameras.
LOW (-40 dB) : For cameras with a sensitive
preamp.
CONTRAST
Adjust the contrast value to change the ratio of
light to dark on the display screen.
RESTORE DEFAULTS
Restores all default factory settings except for
the time and date.
DEVICE DATA
Displays technical device information.
UPDATE FW
Enables firmware updates from the memory
card. Having the latest firmware installed on
the unit is recommended. Please visit www.
shure.com for details.
VP83F HOME
FILE LIST
HEADPHONE
LOW-CUT
MIC GAIN
UTILITIES
FILE_001
PLAY
RENAME
DELETE
DETAILS
BACKLIGHT
TIME/DATE
SD CARD
BATTERY TYPE
CAMERA OUT
CONTRAST
RESET DEFAULTS
DEVICE DATA
FIRMWARE
FORMAT CARD
SET FILE NAME
MAX FILE TIME
SET TIME
SET DATE
