Shure VP83F LensHopper Shotgun Microphone with Integrated Audio Recorder - Manual (Page 9)

9
Specifications
Cartridge Type
Electret Condenser
Polar Pattern
Supercardioid/Lobar
Recording Format
WAV, 24-bit, 48 kHz Sampling Rate
Frequency Response
50 to 20,000 Hz
Sensitivity
open circuit voltage, @ 1 kHz, typical
0 dB Gain -35.8 dBV/Pa [1] (16.2 mV)
+30 dB Gain -5.8 dBV/Pa [1] (512.9 mV)
Maximum SPL
0 dB Gain Setting, 1 kHz at 1% THD [2] , 1000 Ω load
129.2 dB SPL
Signal-to-Noise Ratio [3]
+30 dB Gain Setting
78.4 dB
Self Noise
equivalent SPL, A-weighted, typical, +30 dB Gain
Setting
15.6 dB SPL-A
Operating Temperature Range
-18°C (0°F) to 60°C (145°F)
Storage Temperature Range
-29°C (-20°F) to 74°C (165°F)
Operating Relative Humidity
0 to 95%
Housing
Cast aluminum
Power Requirements
2 AA batteries (Alkaline, NiMH, Rechargeable Li-Ion)
Net Weight
215 g (7.6 oz.)
Camera Output
Connector Type
3.5 mm (1/8") dual mono, Unbalanced
Output Impedance
47 Ω
Headphone Output
Connector Type
3.5 mm (1/8") dual mono
Output Impedance
5 Ω
500 Hz
250 Hz
1,000 Hz
6,300 Hz
10,000 Hz
2,500 Hz
20
15
10
5
0
-30
-25
-20
-15
-10
-5 dB
Hz
20 100 1k 10k 20k
0.6 m (2 ft.) from sound source
[1] 1 Pa=94 dB SPL
[2] THD of microphone preamplifier when applied input
signal level is equivalent to cartridge output at specified
SPL
[3] S/N ratio is the difference between 94 dB SPL and
equivalent SPL of self noise, A-weighted
500 Hz
250 Hz
1,000 Hz
6,300 Hz
10,000 Hz
2,500 Hz
6.6 in (16.8 cm) 2.3 in (5.8 cm)
3.8 in
(9.7 cm)
