DATA SHEET
ARUBA 370 SERIES OUTDOOR ACCESS POINTS
3
• Supported frequency bands (country-specific
restrictions apply):
- 2.400 to 2.4835 GHz
- 5.150 to 5.250 GHz
- 5.250 to 5.350 GHz
- 5.470 to 5.725 GHz
- 5.725 to 5.850 GHz
- 5.825 to 5.875 GHz
• Available channels: Dependent on configured
regulatory domain.
• Dynamic frequency selection (DFS) maximizes the use of
available RF spectrum.
• Supported radio technologies:
- 802.11b: Direct-sequence spread-spectrum (DSSS)
- 802.11a/g/n/ac: Orthogonal frequency-division
multiplexing (OFDM)
• Supported modulation types:
- 802.11b: BPSK, QPSK, CCK
- 802.11a/g/n/ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
• Transmit power: Configurable in increments of 0.5 dBm
•
Maximum (conducted) transmit power (limited by local
regulatory requirements):
- 2.4 GHz band: +25 dBm per chain, +28dBm aggregate (2x2)
- 5 GHz band: +22 dBm per chain, +28dBm aggregate (4x4)
- Note: conducted transmit power levels exclude
antenna gain.
• Maximum EIRP (limited by local regulatory requirements):
- 2.4 GHz band:
» 374: 28 + Antenna Gain
» 375: 32 dBm EIRP
» 377: 34.4 dBm EIRP
- 5 GHz band:
» 374: 28 + Antenna Gain + TxBF Gain
» 375: 35.6 dBm EIRP
» 377: 36 dBm EIRP
• Advanced Cellular Coexistence (ACC) minimizes
interference from cellular networks.
• Maximum ratio combining (MRC) for improved
receiver performance.
• Cyclic delay/shift diversity (CDD/CSD) for improved
downlink RF performance.
• Short guard interval for 20-MHz, 40-MHz, 80-MHz and
160-MHz channels.
• Space-time block coding (STBC) for increased range and
improved reception.
• Low-density parity check (LDPC) for high-efficiency error
correction and increased throughput.
• Transmit beam-forming (TxBF) for increased signal
reliability and range.
• Supported data rates (Mbps):
- 802.11b: 1, 2, 5.5, 11
- 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
- 802.11n (2.4GHz): 6.5 to 300 (MCS0 to MCS15)
- 802.11n (5GHz): 6.5 to 600 (MCS0 to MCS31)
- 802.11ac: 6.5 to 1,733 (MCS0 to MCS9, NSS = 1 to 4 for
VHT20/40/80, NSS = 1 to 2 for VHT160)
• 802.11n high-throughput (HT) support: HT 20/40
• 802.11ac very high throughput (VHT) support:
VHT 20/40/80/160
• 802.11n/ac packet aggregation: A-MPDU, A-MSDU
POWER
• Worst-case power consumption from the AP: 23W
• Power sources sold separately
• Power over Ethernet (PoE+): 802.3at-compliant
• AC Power: 100-240 Volt 50/60Hz AC
OTHER INTERFACES
• One 10/100/1000BASE-T Ethernet network interfaces (RJ-45)
- Auto-sensing link speed and MDI/MDX
- 802.3az Energy Efficient Ethernet (EEE)
• One 1000BASE-X SFP Port
• Bluetooth Low Energy (BLE) radio
- Up to 4 dBm transmit power (class 2) and -91 dBm
receive sensitivity
• Visual indicator (multi-color LED): For system and
radio status
• Reset button: Factory reset (during device power up)
• Micro USB console interface
• Kensington security slot
MOUNTING
• Optional mounting kits:
- AP-OUT-MNT-V1A: Outdoor Pole/Wall Long Mount Kit
- AP-270-MNT-V2: Outdoor Pole/Wall Short Mount Kit
- AP-270-MNT-H1: Outdoor AP Hanging or Tilt Install
Mount Kit
- AP-270-MNT-H2: Outdoor Flush Wall or Ceiling Mount
- AP-270-MNT-H3: Outdoor AP Hanging or Dual-Tilt Install
Mount Kit
