DATA SHEET
ARUBA 370 SERIES OUTDOOR ACCESS POINTS
4
MECHANICAL
AP-374
Dimensions/weight (excluding mount):
• 23 cm (W) x 24 cm (D) x 19 cm (H) with aesthetic cover
• 9.0” (W) x 9.4” (D) x 7.5” (H)
• 2.7 kg/6 lbs
• 23 cm (W) x 24 cm (D) x 14 cm (H) without aesthetic cover
• 9.0” (W) x 9.4” (D) x 5.5” (H)
• 2.4 kg/5.3 lbs
AP-375
Dimensions/weight (excluding mount):
• 23 cm (W) x 24 cm (D) x 27 cm (H)
• 9.0” (W) x 9.4” (D) x 10.6” (H)
• 2.4 kg/5.3 lbs
AP-377
Dimensions/weight (excluding mount):
• 23 cm (W) x 22 cm (D) x 13 cm (H)
• 9.0” (W) x 8.7” (D) x 5.1” (H)
• 2.1 kg/4.6 lbs
ENVIRONMENTAL
• Operating:
- Temperature: -40° C to +65° C (-40° F to +149° F)
- Humidity: 5% to 95% non-condensing
• Storage and transportation:
- Temperature: -40° C to +70° C (-40° F to +158° F)
• Operating Altitude: 3,000 m
• Water and Dust
- IP66/67
• Salt Tolerance
- Tested to ASTM B117-07A Salt Spray 200hrs
• Wind Survival: Up to 165 Mph
• Shock and Vibration ETSI 300-19-2-4
REGULATORY
• FCC/ISED
• CE Marked
• RED Directive 2014/53/EU
• EMC Directive 2014/30/EU
• Low Voltage Directive 2014/35/EU
• UL/IEC/EN 60950
• EN 60601-1-1, EN60601-1-2
• Railway Certs:
- EN 50155:2017 – Railway Applications
- EN 50121-1:2017 – Railway EMC
- EN 50121-3-2 – Railway EMC
- EN 50121-4:2016 – Railway Immunity
- IEC 61373 ed2:2008 – Railway Shock and Vibration
For more country-specific regulatory information and
approvals, please see your Aruba representative.
REGULATORY MODEL NUMBERS
• AP-374: APEX0374
• AP-375: APEX0375
• AP-377: APEX0377
CERTIFICATIONS
• CB Scheme Safety, cTUVus
• UL2043 plenum rating
• Wi-Fi Alliance certified 802.11a/b/g/n
•
WPA, WPA2 and WPA3 – Enterprise with CNSA option,
Personal (SAE), Enhanced Open (OWE)
• Wi-Fi CERTIFIED™ ac (with wave 2 features)
• Passpoint ® (Release 2) with ArubaOS and Instant 8.3+
WARRANTY
• Limited lifetime warranty
MINIMUM OPERATING SYSTEM SOFTWARE
• ArubaOS & Aruba InstantOS 8.3.0.0
