4
INPUT CABLE ASSEMBLIES
14 Pin/Twist-Mate™ Cables
K591
Rated 400 amps, 60% duty cycle:
2/0 (67mm
2 ) cable with
Twist-Mate™ and 14 pin MS-type
connector. 10, 25 and 50 ft. (3, 8,
15m) lengths.
Order K591-10, -25, or -50.
K593
Same as K591 but includes gas and
water hoses in 10 ft. (3.0 m) length.
Order K593-10.
14 Pin/Stud Cables
K592
Rated 600 amps, 60% duty cycle:
3/0 (85mm
2 ) cable with lugs and 14
pin MS-type connector. 10, 25 and
50 ft. (3, 8, 15m) lengths.
Order K592-10, -25, or -50.
K619
Rated 350 amps, 60% duty cycle: 1/0
cable (53mm
2 ) with lugs and 14 pin
MS-type connector. 10, 25 and 50 ft.
(3, 8, 15m) lengths.
Order K619-10, -25 or -50.
REQUIRED
OPTIONS
THE TOTAL
SOLUTION DRIVE ROLL AND
GUIDE TUBE KITS
2 roll 4 roll
Steel Wire Sizes:
.023-.025 (0.6mm) solid
KP653-025S KP655-025S
.030 (0.8mm) solid KP653-030S KP655-030S
.035 (0.9mm) solid KP653-035S KP655-035S
.035 (0.9mm) cored KP653-035C KP655-035C
.045-.052 (1.2-1.3mm) solid KP653-052S KP655-052S
.045-.052 (1.2-1.3mm) cored KP653-052C KP655-052C
.052-1/16 (1.3-1.6mm) solid or cored (1) KP653-1/16 KP655-1/16
.068-3/32 (1.7-2.4mm) cored (1) KP653-3/32 KP655-3/32
Aluminum Wire Sizes:
.035 (0.9mm)
KP654-035A KP656-035A
3/64 (1.2mm) KP654-3/64A KP656-3/64A
1/16 (1.6mm) KP654-1/16A KP656-1/16A
(1) Not for LN-742H models.
Choose from a complete line of
Lincoln products to generate the total
solution for your welding application:
• CV-250, CV-300, CV-400, CV-655
CV400-I, CV500-I, DC-400,
DC-600*, and DC-655.
• Invertec™ V350-PRO and V300-I
power sources.
• Ranger 9, Ranger 275, Ranger 300
DLX, Commander 300* and 500*
engine driven welders.
• MIG and flux-cored gun and cable
assemblies.
• A full line of MIG and FCAW wires.
* Must buy optional 42VAC Kit for Codes below
10500.
