Lincoln Electric LN-742 - Manual (Page 6)

6
OPTIONS
AVAILABLE
Caster Kit - Light Duty
Mounts to the K1524-1 wire reel
stand. Allows for easy movement
of wire feeder. Order K1556-1.
K1556-1
READI-REEL ® ADAPTERS
30 lb. (14 kg) Adapter
Adapts 22-30 lb. (10-13.6 kg) Lincoln
Readi-Reels of electrode to 2”
(51mm) spindle. Order K363P.
Quantity of 15, Order K363P-15.
K1524-1
K438
K363P
COIL ADAPTER
60 lb. (27.2 kg) Adapter
Adapts 60 lb. (27.2 kg) coils of Lincoln
electrode to 2” (51mm) spindle.
Order K1504-1.
K1504-1
WIRE REEL STAND
For use with 50-60 lb. (22.7-27.2 kg)
coils. Includes 1” (25.4mm) spindle,
wire reel, lift bail and dust shield.
Order K303.
K303
50-60 lb. (27.2 kg) Adapter
Adapts 50-60 lb. (22.7-27.3 kg)
Lincoln Readi-Reels of electrode to 2”
(51mm) spindle. Order 438.
Quantity of 15, Order K438-8.
SPINDLE ADAPTERS
For Readi-Reels and Spools
2” O.D. spindle for mounting Readi-
Reels and 2” (51mm) I.D. spools up to
60 lb. (27.2 kg) capacity to a K303
stand. Order K162-1.
For 14 lb. (6 kg) Innershield® Coils
Permits 14 lb. (6 kg) Innershield
electrode coils to be mounted on 2”
(51mm) O.D. spindles. Order K435.
Universal Wire Reel Stand
For use with Lincoln 10-60 lb.
(4.5-27.2 kg) wire packages that use a
2” (51mm) spindle. Hole in stand fits
over lift bail. Optional swivel platform
is K1557-1. Order K1524-1.
Water Solenoid Kit
Includes solenoid and fittings for use
with water-cooled guns and Magnum
water coolers. Order K590-1.
