2.12
Connecting external devices
The figure below shows the specific connectors and devices that you can
connect to the rear panel ports.
Serial
PS/2 KB
VGA
Line Out
Line In
Mic
PS/2 Mouse
AC
Parallel
USB
RJ-45
