19
Variety Steamer
P/N 1010745 Rev. g 03/06
trOUblesHOOtInG
warnInG
to avoid possible personal injury and/or damage to the unit, inspection, test and repair of electrical equip-
ment should be performed by qualified service personnel. the unit should be unplugged when servicing,
except when electrical tests are required.
problem possible cause corrective action
Rocker switch (power
On/Off) is turned on but
the switch indicator Light
is still off and the control
Panel is blank
Power cord not correctly plugged in. Plug in the power cord correctly.
the power cord and/or electrical plug
is damaged.
inspect electrical wire, plug, and receptacle.
the main electrical panel circuit break-
er is off or has been tripped.
Reset circuit breaker. contact your mainte-
nance person or authorized service agency if
it trips again.
Rocker switch is inoperable. contact your maintenance person or
authorized service agency for service.
the unit’s main electri-
cal panel circuit breaker
trips.
Damaged receptacle, plug, or cord; a
loose connection or an internal compo-
nent failure.
turn the unit off, allow it to cool to room tem-
perature, and then restart the unit.
Power On/Off switch and
indicator are on but the
display is blank.
control board is inoperable. contact your maintenance person or
authorized service agency for service.
transformer is inoperable.
Loose or burnt wiring in heating circuit.
Power On/Off switch is
turned on, the switch
indicator light is on, the
control panel display is
on, but the unit is not
heating up.
Heat Relay is inoperable. Reset the Hi-Limit thermostat according to
the Operations section of this manual. if the
Hi-Limit thermostat requries continuous reset-
ting, contact your maintenance person or
authorized service agency for service.
Hi-Limit thermostat is tripped.
thermocouple is inoperable.
control board is inoperable.
steam generator is inoperable.
Loose or burnt wiring in heating circuit.
unit heats but there is lit-
tle or no steam produced
and/or
the product requires
more steaming than
usual.
Water Line Valve is closed. check that the Water Line Valve is open.
filter strainer is restricted. check and clean the filter strainer as
described in the Maintenance section of this
manual.
Quick Disconnect is not fully engaged
at rear of the unit or is damaged.
Remove and reengage the Quick Disconnect
firmly until a “click” is heard. Replace if dam-
aged.
Low or no water pressure in water line. Remove the Quick Disconnect insert from the
rear of the unit. While holding into an empty
cup, press the white plastic tip. strong steady
water flow should be noted. if so, re-engage
firmly into unit. if not present, or pressure
is low, contact your maintenance person or
plumber.
spray tube is restricted. Remove and clean spray tube as described
in the Maintenance section of this manual.
black Manifold orifices are restricted. Remove and clean the black Manifold as
described in the Maintenance section of this
manual.
unit is not being cleaned daily or prop-
erly.
clean unit daily as described in the
Maintenance section of this manual.
