AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
With 6 ohm loads, both channels driven, from
120 – 20,000 Hz; rated 60 watts per channel
minimum RMS power, with no more than 0.7%
total harmonic distortion from 250 milliwatts to
rated output.
Amplifier section
Power Output
1)
(6 ohms 1 kHz, THD 10%)
FRONT
2)
: 100 W/ch
CENTER
2)
: 100 W
SURR
2)
: 100 W/ch
(6 ohms 100 Hz, THD 10%)
SUB WOOFER
2) : 100 W
1) Measured under the following conditions:
120 V AC, 60 Hz
2) Depending on the sound field settings and the
source, there may be no sound output.
Inputs (Analog)
Inputs (Digital)
Output (Analog)
Reproduction frequency range:
28 – 20,000 Hz
Tone
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range
With 10-kHz tuning scale: 530 – 1,710 kHz
3)
With 9-kHz tuning scale: 531 – 1,710 kHz
3)
Antenna Loop antenna
Intermediate frequency 450 kHz
3) You can change the AM tuning scale to 9 kHz or
10 kHz. After tuning in any AM station, turn off the
receiver. While holding down PRESET TUNING +
or TUNING +, press ?/1. All preset stations will be
erased when you change the tuning scale. To reset
the scale to 10 kHz (or 9 kHz), repeat the procedure.
General
Power requirements 120 V AC, 60 Hz
Power consumption 160 W
Power consumption (during standby mode)
0.2 W
Dimensions (w/h/d) (Approx.)
430 Ч 145 Ч 301.5 mm
(17 Ч 5 6/8 Ч 11 7/8 inches)
including projecting parts
and controls
Mass (Approx.) 6.5 kg (14 lb 6 oz)
Specifications
SA-CD/CD, DVD,
VIDEO 1, 2 Sensitivity: 800 mV
Impedance: 50 k ohms
DVD (Coaxial) Sensitivity: –
Impedance: 75 ohms
SA-CD/CD (Optical) Sensitivity: –
Impedance: –
SUB WOOFER Voltage: 2 V
Impedance: 1 k ohm
Gain levels ±6 dB, 1 dB step
continued
