EN
ENGLISH
Clarke
®
American Sanders
Operator's Manual (EN) - Floorcrafter
- 35 -
BASE ASSEMBLY
Item
Ref. No. Qty Description
1
920342
2
Nut Esna 3/8-16
2
962892
2
Screw 1/4-20 Unc X 3/4 Pan Head
3
980349
1
Washer Wear Cam
4
980645
1
Washer, 3/8” S.A.E. Flat
5
56109699 1
Cam Assy With Grip
6
50793A
2
Wheel
7
50986A
1
Frame Main Sander
8
52348A
1
Link Arm Right
9
52349A
1
Link Arm Left
10
57120A
1
Plug-Button
11
70499A
1
Label Cas
12
73285A
1
Label Warning
13
80087A
1
Screw 3/8-16 X 6.00
14
80189A
2
Washer Wave
15
87035A
2
Washer 10 Fenderss
16
87050A
4
Washer Flt 1.0 X .63 X .06 Nyl
