HANDLE ASSEMBLY
Item
Ref. No. Qty Description
1
445178
1
Label-Inter Lock
2
500241
2
Adapter Switch Fm
3
505140
2
Lever Switch Fm
4
508340
2
Spring-Switch Lever Fm
5
908275
1
Cord Asm Ext. 50 Fm1500-170
6
911690
2
Switch Fm1500-2300 Mp18 Cline
7
920110
1
Nut, 5/16-18 Hex Lock
8
962015
2
Screw 10-24 X 3/8 Pn St Ph
9
962241
2
Screw, 10-24 X 1/2
10
962289
4
Screw, 1/4-20 X 3/4
11
962391
1
Screw 10-24x1 Sc St Cap
12
10304A
1
Adaptor Wldmt., Hose
13
22109A
1
Cover, Switch Housing
14
24507A
1
Housing Handle/Switch Fm 150
15
24508A
1
Housing-Switch Front
16
34612B
1
Griphandle Left Gp-18
17
34613B
1
Grip Handle Right Gp-18
18
38004A
1
Stop-Switch Interlock
19
40530A
1
Cord Lamp Inteconnect
20
40927A
1
Cord, Interconnect
21
50781A
1
Clamp, Handle
22
50794A
2
Bushing Nylon C2k
23
50796A
1
Bushing Cord C2k
24
53742A
1
Tube, Handle
25
61120A
1
Bracket-Switch Stop
26
67900A
1
Spring-Switch Lever
27
70175A
1
Tag Warning
28
71141A
1
Label Handle 1600 Sander
29
80290A
1
Screw 10-32 X .38 HRCS
30
80291A
1
Washer, Flat #10 (.203x.734x.063)
31
83003A
4
Rivet 1/8 X 3/8
32
84807A
2
Screw 6-32 X 1 5/8 Pan Hd
33
88643A
1
Bolt Carriage 5/16-18x1 ¼
34 70175A-FR 1
Tag Warning Eng-Frn
