Atlona Technologies’ AT-SAV-42M is a 4x2 S-Video/Composite Video and Analog Audio Matrix Switcher de-
signed to work as a switcher for multiple Audio/Video sources and displays. This Atlona unit is capable of
switching Composite Video, S-Video and Stereo Audio signals between four sources and two displays. Because
it is a matrix switch, any or all of the 4 inputs can simulta¬neously be switched to either or both of the outputs.
With a maximum bandwidth of 260MHz, this devise will support sharp and highly defined video in multiple
resolutions of up to 480i/576i. This unit has quick and easy installation. With manual as well as IR Remote con-
trol options, Atlona’s AT-SAV-42M Matrix Switcher is perfect for all Video equipment that using S-Video signal
such as Cable and Satellite receivers, VCRs, DVD Players, Set Top Boxes...etc.
• 4x2 Matrix Switcher (AT-SAV-42M)
• Instruction Manual
• IR Remote Control
• Universal AC/DC poweradapter: 12VDC (110-240V)
• 3-RCA to 3-RCA cable 6ft (2m)
• S-Video to S-Video cable 6ft (2m)
• Switches S-Video, Composite Video and Analog Audio between 4 sources and 2 displays.
• Matrix Switch: each input can be directed to either or both outputs at the same time
• IR Remote control or Manual
• Supports resolutions up to 480i & 576i
• Quick and easy installation
INTRODUCTION
PACKAGE CONTENTS
FEATURES
