Code Comment
‘MD’+0
‘MD’+1 move DOWN move DOWN button release
move DOWN button press
‘ML’+0
‘ML’+1 move LEFT move LEFT button release
move LEFT button press
‘ML’+0
‘ML’+1 move RIGHT move RIGHT button release
move RIGHT button press
‘SU’+0
‘SU’+1 size UP shorter height image button release
shorter height button press
‘SD’+0
‘SD’+1 size DOWN higher height image button release
higher height image button press
‘SL’+0
‘SL’+1 size LEFT narrower width image button release
narrower width image button press
‘SR’+0
‘SR’+1 size RIGHT wider width image button release
wider width image button press
‘RS’+0
‘RS’+1
‘RS’+2
‘RS’+3 RESET system reset
reset image location
reset image size
reset video settings
‘TP’+0
‘TP’+1 PATTERN test pattern off
test pattern on
‘0F’+0
‘0F’+1
‘0F’+2 Output Format CV/SV output
RGB output
YUV output
‘AR‘+value zoom AREA ‘AR’+1 ~ ‘AR’+9 zoom area1 ~ area9
‘AS’+0
‘AS’+1 ASPECT aspect is 4:3
aspect is wide screen
‘CO‘+value
‘BR‘+value
‘SA‘+value
‘FF‘+value CONTRAST value = 0 ~ 63
BRIGHTNESS value = 0 ~ 255
SATURATION value = 0 ~ 63
FLICKER value = 0 ~ 21
‘VR’+1 VERSION require AT-PC-AVSCOMP unit firmware version
‘AL’+1 ALL retrive AT-PC-AVSCOMP all status
retrive ‘PW’+0 only when unit power off
‘PW’+1 ‘NP’+?
‘OV’+? ‘AS’+?
‘ZM’+? ‘CO’+?
‘BR‘+? ‘SA’+?
‘SH’+? ‘FF’+?
