Step 2: load a copied EDID onto an input
---> ---> ---> --->
AT-H2H-XXM
Select Input Number Select Function Option
home screen
1 To copy up to 4/8 EDIDs
2 To choose input EDID
Input #
Select an input port Input # Press Enter
Current: Default
Input: # Mode:
1.Default 2.Saved 3.Int Input: # Select saved
EDID memory 1-4/8 (#)
Use EDID memory # + enter
_ _ _
--->
--->
Feedback = ”Save memory # EDID
to input #”
--->
--->
--->
---> --->
---> ---> ---> --->
--->
Atlona EDID - ATL
Pioneer EDID - PIO
Toshiba EDID - TSB EX.
Once EDIDs have been copied to memory they can be loaded to a specific input.
Note: (refer to the diagram on page 9) Using the EDID of output 3 with input 1 will enable 1080p,
3D, and Dolby TrueHD to pass. Output 2 will receive no audio or video and output 1 will receive no
audio with these settings.
memory selection
input selection
through
through
