INTRODUCTION
PACKAGE CONTENTS:
FEATURES:
The Atlona AT-AV0808N is a true matrix switcher with 8 composite video and stereo audio
inputs and outputs. Because it is a matrix switch you can associate any of the 8 A/V inputs
to any of the 8 outputs. This gives you great flexibility over other ordinary switchers!! The
AT-AV0808N can be used with up to 8 sources such as a VCR or DVD and connected to up
to 8 displays. There are several remote control options such as the supplied hand held IR remote,
RS-232 for computer or touch panel control and an IR extender solution for control from another
zone. Operation can be achieved from the front face panel or remotely.
• 1 X Atlona AT-AV0808N (8 X 8 composite video + stereo audio matrix switcher)
• 1 X 12VDC power supply with detachable power cord
• 1 X instruction manual
• 1 X RS-232 cable
• 1 X control software package
• Rack-Ears (pair)
• 1 X IR remote control
• 1 X IR extender kit
• Composite video + stereo audio 8 x 8 matrix switcher
• Able to independently select up to 8 sources and associate them to any or all of
up to 8 connected displays
• Compatible with all composite video devices such as VCR or DVD
• Remote solutions include hand held IR remote control (included), IR extender
(included) and RS-232
(cable included) for computer or touch panel operation
• Control software package for RS-232 operation
• Manual control via front panel buttons
• LCD read out provides live visual status for all inputs and outputs
• Supports NTSC or PAL video systems
• Inputs: 8 X A/V (composite video + stereo audio), 1 x IR EXT, 1 x RS-232
• Outputs: 8 X
A/V (composite video + stereo audio), 1 x RS-232
• Power Supply: 12VDC (universal 110/220v)
• Dimensions (W X D X H): 17.50” X 8.25” X 2” (444.5 X 209.55 X 50.8mm)
• Weight: 5.41LB (3.25Kgs)
SPECIFICATIONS:
