Atlona AT 3GSDI 16 User Manual
Page 2
1
www.atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
1. INTRODUCTION
...................... 1
2. PACKAGE CONTENTS
...................... 1
3.
FEATURES
......................
1
4. SPECIFICATIONS
...................... 2
5. PANEL DESCRIPTIONS
...................... 3
5.1. Transmitting Module
...................... 3
5.1.1. Front Panel
...................... 3
5.1.2. Rear Panel
...................... 3
6. CONNECTION DIAGRAM
...................... 4
7. INSTALLATION
...................... 4
8. SAFETY INFORMATION
...................... 5
9. WARRANTY
...................... 6
10. ATLONA PRODUCT REGISTRATION ...................... 7
11. SIGNAL MEASUREMENT
...................... 8
The AT-3GSDI-16 1x6 3G/HD/SD-SDI Splitter with Reclocking receives one SDI input, perfectly duplicates it,
and re-transmits six SDI outputs for real time multi-viewing. It is a reliable video device splitting a SDI, HD-SDI,
or 3G-SDI video source to six SDI compliant displays at the same time.
• 1x AT-3GSDI-16
• 1x5V universal power supply
• 1x User’s manual
• 3G/HD/SD triple-rate distribution
• Four separately buffered and reclocked outputs
• Cable equalization (Beldon 1694A) and signal retiming
• Dual color LED indication of input lock and rate
• Passes all ancillary data
• Provides automatic input cable equalization up to 300m (1000ft)@SD, 150m (500ft)@HD and 90m (300ft)
• Reclocking SDI signals for cascading and thus longer transmission
• Inter-locked power supply for better fixedness
TABLE OF CONTENTS
INTRODUCTION:
PACKAGE CONTENTS:
FEATURES:
