Technical Transmitter Receiver
Role of usage Transmitter [TX] Receiver [RX]
HDMI TM compliance High Speed HDMI TM - Deep Color & full 3D support
HDCP compliance Yes
Video bandwidth Single-link 6.75Gbps [225MHz]
Video support 480i/p / 720p (50/60) / 1080i (50/60) / 1080p (30/50/60)
HDMI TM over UTP
transmission
Full HD (1080p)-130ft (40m) [CAT5e] / 165ft (50m) [CAT6] HD (720p/1080i)-
165ft (50m) [CAT5e] / 200ft (60m) [CAT6]
Audio support Surround sound (up to 7.1ch) or stereo digital audio
Signal Equalization 8-level digital control at RX
Input TMDS signal 1.2 Volts [peak-to-peak]
Input DDC signal 5 Volts [peak-to-peak, TTL]
ESD protection [1] Human body model — ±19kV [air-gap discharge] & ±12kV [contact discharge]
[2] Core chipset — ±8kV
PCB stack-up 4-layer board [impedance control — differential 100Ω; single 50Ω]
Input 1x HDMI TM ; 1x 3.5mm 1x RJ45; 1x 3.5mm
Output 1x RJ45; 1x 3.5mm 1x HDMI TM ; 1x 3.5mm
HDMI TM connector Type A [19-pin female]
RJ45 connector WE/SS 8P8C with 2 LED indicators
Rotary control switch EDID Mode Signal level
Mechanical
Housing
Metal enclosure
Dimensions
[L x W x H]
Model 2.9” x 3.5” x 1” (75 x 90 x 25mm)
Package 6.9” x 10.6” x 3.1” (175 x 270 x 80mm)
Carton 1’3” x 1’6” x 1’ (370 x 450 x 300mm)
Weight Model 1.1 lbs (480g)
Package 1.7 lbs (780g)
Fixedness Wall-mounting case with screws
Power supply 5V 2A DC
Power consumption 1.5 W
Operation temperature 32~104°F (0~40°C)
Storage temperature -4~140°F (-20~60°C)
Relative humidity 20~90% RH (no condensation)
SPECIFICATIONS:
