10
Directions for use SOL 80 ALU IP 44
Alternatively charge with external charger:
You can charge the appliance before first use with a suitable charger (not supplied).
Remove the batteries from the lamp and charge directly in the battery charger.
Check the charger specifications. The charger must be compatible for charging NiMH
batteries (AA / 1.2 V / 2200 mAh).
INSTALLATION INSTRUCTIONS SOLAR MODULE AND LAMP
Figure A (South) Figure B (South)
LED lamp:
The lamp consists of a light fitting with 8 high performance LEDs, a light casing with
battery compartment and a rotating movement detector. Observe the motion detector’s
detection area when selecting the installation location. The movement detector has a
range of 10 m in an angle of 130° horizontally at an ambient temperature of 25 °C.
The recommended installation height above ground level is 2 m to 2.5 m.
Install the lamp’s mounting plate with the supplied screws on a suitable surface.
Place the lamp on the mounting plate and secure with the safety screw (see Figure A).
Solar module:
The solar module converts the radiation energy in the sunlight in electric energy. This
environmentally friendly solar energy charges the batteries and allows the use of this
lamp independently from mains power supply. Please remember that the installation site
of the solar module needs direct sunlight for best performance. Do not place the module
in the shade and direct it South, if possible. In Central Europe a tilt angle of approx. 30° is
recommended. This also ensures to a certain degree self-cleaning from leaves, dust and
snow by wind and rain. Install the solar module with the supplied mounting screws on a
solid surface. Set the tilt angle accordingly with the mounting bracket (see Figures A
and B). Adjust the solar module to the desired direction.
SOUTH
SOUTH
