11
Directions for use SOL 80 ALU IP 44
SETUP AND OPERATION
After successful installation connect the solar module cable with the lamp.
The solar LED lamp is now ready to use.
Important:
Remember to charge the batteries before first use of the lamp. The switch must be in
OFF position. Charging with the solar module takes approximately 3-4 sunny days.
SWITCH SETTINGS:
On top of the lamp casing you find the main switch with two possible settings (Figure C):
ON:
Position when switched on.
The batteries are charged via the solar module, the lamp is activated via the
motion detector.
OFF: Lamp and movement detector are switched off, battery charging via solar module
still active.
Position during delivery and recommended position during longer periods of
non-use.
Switch position during fast battery charge without operational lamp.
Figure C
MOVEMENT DETECTOR
This is a passive infrared sensor detecting motion due to heat radiation changes within
the protected area, which turns the lamp on/off.
Set the main switch after initial charging to ON position.
Turn the movement detector until you have access to the control knobs (see Figure D).
Figure D
ON OFF
LUX TIME SENS
