Directions for use SOL 80 ALU IP 44
3. Problem: Lamp flashes fast.
Solution: The batteries are exhausted. Set switch to OFF position and charge the
batteries for at least 3-4 days in direct sunlight. Afterwards set the switch back to ON
position.
4. Problem: Luminosity is weaker than usual.
Solution: The batteries are exhausted. Set switch to OFF position and charge the
batteries for at least 3-4 days in direct sunlight. Afterwards set the switch back to ON
position.
TECHNICAL DATA
Illuminant: 8 high performance LEDs (8 x 0.5 W)
Luminous flux approx. 350 lm
Luminous period: Up to 110 minutes with fully charged batteries
Solar module: P= 2 W
p
U
pm
= 10 V
I
pm
= 140 ± 10 mA
Dimensions: 210 x 160 x 16 mm
Motion detector: Type: PIR
Detection angle: 130° horizontal
Range: max. 10 m at 25 °C ambient
temperature
and 2 m to 2.5 m installation height
Light duration adjustable between 10 ± 5s to 60 ± 10s
Response threshold continuously adjustable between
daylight and night (approx. 2-2000 lx)
Connecting cable: 5 m (solar module – lamp; 4,75 + 0,25 m)
Batteries: 3 x NiMH / AA / 1.2 V / 2200 mAh
Charge protection: Overcharge protection and discharge protection
Protection class: IP 44
Ambient temperature: –5 °C to +45 °C
Weight: approx. 1.3 kg
DISPOSAL
Dispose of waste electric and electronic appliances environmentally responsible.
Do not dispose of electrical appliances with the household waste. According to
European directive 2002 / 96 / EG for waste electric and electronic appliances and
national implementation waste electric appliances must be collected separately and must
be environmentally friendly recycled. Enquire at your municipally collection points for
waste electric and electronic appliances.
Environmental damages caused by incorrect battery disposal!
Batteries and rechargeable batteries do not belong in the household waste.
They can contain toxic heavy metals and must be disposed of as hazardous waste.
Return exhausted batteries to a municipal collection point.
