7
METER SETTINGS SCREEN
Press the SET key to access the settings screen (fig. 2). Options include the
following: 1) selecting between CATV or VHF/UHF channels 2) selecting
between dBuV or dBmV measurement units, 3) adjusting the volume and display
contrast levels, and 4) creating or editing a user-defined channel list.
VOL 1
CON 37 %
dB dBµ




































VOL UP DOW ESC
Fig.2
meter settings screen
1. The ST5128 offers the choice to measure either USA CATV or VHF/UHF
channels. To select between CATV or VHF/UHF channels:
1. Press the SET key to enter the Settings screen.
2. Press the F2 (UP) soft key to move the cursor to CTS
3. Use either of the
keys to toggle between CATV or VHF/UHF.
4. Press the F4 (ESC) soft key to return to the single channel
measurement mode screen and the main menu.
2. To select between dbuV and dBmV measurement units:
1. Press the SET key (if not already in the settings screen)
2. Press the F3 (DOW) soft key twice to move the cursor to dB:
3. Use either of the
keys to toggle between dBmV or dBuV.
4. Press the F4 (ESC) soft key to return to the single channel
measurement mode screen and the main menu.
3. To adjust the volume level:
1. Press the SET key (if not already in the settings screen).
2. Press the F1 (VOL) soft key to move the cursor to VOL.
3. Use the
keys to increase or decrease the volume level.
4. Press the F4 (ESC) soft key to return to the single channel
