FEATURES
1. 1/2.7” CMOS Sensor
2. 1080P video output
3. Low light sensitivity of 0.1 Lux / F1.8, 0Lux (IR LED ON)
4. Day and night 24-hour surveillance with IR effective distance up to 15 meters
PACKAGE CONTENT
 IR camera  User manual  Wrench  Screws & wall plugs
DIMENSIONS*
*Dimensional Tolerance: ± 5mm
SPECIFICATIONS*
Pick-up Element 1/ 2.7” CMOS image sensor
Number of Pixels 1930(H) x 1088(V)
Video Frame Rate 1080P@30fps / 1080P@25fps
Min. Illumination 0.1 Lux / F1.8, 0 Lux (IR LED ON)
S/N Ratio More than 48dB (AGC OFF)
Shutter Speed 1/30 (1/25) sec ~ 1/720000 (1/600000) sec
Lens f3.6mm / F1.8
Lens Angle 96° (Horizontal) / 50° (Vertical) / 116° (Diagonal)
IR LED 12 units
IR Effective Distance Up to 15 meters
IR Shift YES
Day & Night Mode YES
IRIS Mode AES
White Balance AUTO / USER / PUSH / 8000K / 6000K / 4200K / 3200K
AGC Adjustable
Sharpness Adjustable
Flickerless 50HZ / 60HZ / OFF
BLC Adjustable
IP Rating IP66
Operating Temperature -20℃ ~ 40℃
Video Output 1.0 Vp-p composite, 75Ω
Power Source (±10%) DC12V / 0.5A
Current Consumption (±10%) 200mA
* The specifications are subject to change without notice.
