CONNECTION
1. DC12V Input Terminal
Connect the power terminal of the camera to a DC 12V regulated power supply.
NOTE: Please use the correct power adaptor, DC12V (regulated), to operate this unit. The power
tolerance of this unit is DC12V ± 10%. Over maximum DC 12V power input will damage this
unit.
2. Video Output Connector (VIDEO OUT)
Connect the camera video output to the video input of a DVR with 75Ω coaxial cable.
NOTE: To ensure the camera has sufficient protection against moisture, an extra waterproof
measure, such as by using an insulating tape, must be used to cover the power and video
connectors after connection.
CAMERA PARAMETERS
This camera series has its own configuration menu, and either of the two methods below is available to
access the menu based on the camera model you have.
NOTE: The methods below are available only when the camera is used with our brand’s HD CCTV
DVR.
 Method 1
On the DVR live view, click the channel which connects this camera to display in the full screen mode,
and select .
 Method 2
On the DVR live view, right click to show the DVR main menu, and select “ADVANCED CONFIG” 
“DCCS”. Then, select the channel which connects this camera, and click “SETUP” to enter the menu of
camera parameters.
ADVANCED CONFIG
CAMERA CH1 CH2 CH3 CH4
DETECTION MENU SETUP
ALERT
NETWORK
DISPLAY
RECORD
DEVICES
DCCS DEVICE XXXXX
NOTIFY CONNECTION OK
EXIT
