Argox OS-2130D - Manual (Page 14)

14
OS-2130D & OS-2130DE User’s Manual
Ready LED
 When printer is started, the READY indicator
will blink. In Ethernet model, the READY
indicator will blink for several seconds to wait
till and stop blinking when Ethernet Card is
ready.
 When printer receives data from host PC,
READY indicator will start blinking.
 READY indicator will blink when printing is
paused.
 It will start blinking while “Media Out”, “Media
Gap Not Found” has been detected.
 It will blink as soon as the printer module is
opened.
Note:
When the print head is over-heated, printer’s
thermal protection function will be activated and
make READY LED blink to indicate printer is in
PAUSE status to wait till print head has been
cooled down. The printing tasks sent previously
will be resumed automatically later.
15
OS-2130D & OS-2130DE User’s Manual
Feed Button
 Press to advance the label media to the first
printing position.
 Press during printing to make printer "pause".
 Press and hold while switching on the power to
conduct media calibration and print out a
configuration profile.
 To resume printing after “Media Out “ errors
have been resolved.
