Connecting Your DCX Set-top
B
DCX with OCAP Software DCX3510-M • User Guide
19
365-095-17068-x.1
Connecting an A/V Receiver, SDTV, and VCR/DVD Recorder
1. Connect a stereo audio cable to the AUDIO OUT L/R connectors on the DCX set-top
and the input L/R connectors on the A/V receiver.
2. Connect a Video Composite cable to the Video Composite connector on the DCX
set-top and the Video Composite connector on the A/V receiver.
3. Connect a stereo audio cable to the VCR AUDIO OUT L/R connectors on the A/V
receiver and the INPUT AUDIO L/R connectors on the stereo VCR.
4. Connect a stereo audio cable to the output AUDIO OUT L/R connectors on the
stereo VCR and the VCR audio in L/R connectors on the A/V receiver.
5. Connect a composite video cable to the input video connector on the stereo VCR
and the video VCR OUT connector on the A/V receiver.
6. Connect a composite video cable to the output video connector on the stereo VCR
and the video VCR IN connector on the A/V receiver.
7. Connect a Composite Video cable to the input Composite Video connector on the
Standard-Definition TV (SDTV) and the TV/monitor output Composite Video
connector on the A/V receiver.
Note: The digital audio optical (optical S/PDIF) audio outputs may be used in place of the
stereo audio outputs (audio L/R). Optial S/PDIF offers a higher level of audio quality,
including support for Dolby Digital audio.
These video connection methods do not support HD video. If you have an HDTV, see
