Page 46: Head temperature adjustment
10/07 Rev. AA
MANUAL EASY PLUG
Commands
All
devices
A = TTX 600 --TLX 604 – Eagle B = TTX 300 Offline -- Cobra Offline D = TTX 300 Online –TTX 207 -- Cobra Online – Da Capo
E = TTX 450/650/674/675/950/1050 – Puma/Puma plus/Lion/Lion plus/Tiger/Tiger XXL -- S45/65/95/105 -- TDI/STDI/XXTREME
G = TTX 350 – Ocelot – TTK – Texxtile H = 64-xx –Chess x –TT4 – DPM – PEM – ALX 92x – AP 4.4/5.4
46
H
#HR
Head resistance adjustment
Definition
Sets the head resistance to the required value n (in ohms). This allows the
head temperature to be adjusted to the print head.
Syntax
#HRn
Group
D
Group B (TTX 300/Cobra offline only)
n = int
Head resistance (425 to 575 for TTX 300) (500 to 600 for TTX 207)
425 or 500 = lowest head resistance
575 or 600 = highest head resistance
Incorrect head resistance settings reduce the service life of the print head.
#HV
Head temperature adjustment
Definition
Sets the head voltage and therefore the head temperature to the required
value n.
Command must stand outside of #ER and #Q!
Syntax
#HVn
Groups E, G, H
n = int
Head temperature (0 to xxx)
0 = lowest head temperature
xxx = highest head temperature (value depends on the printer type, see
table below)
Printer
max. HV value
TTX 67x, TDI, TTK, TTX 350, ALX 720
99
64-xx, DPM, PEM, ALX 92x
110
AP 4.4, AP 5.4, AP 7.t
120
CAUTION!
The printhead temperature (= HV-value) directly affects the life of a
printhead. It counts: “The higher the temperature, the printhead is driven
with, the lower is its life durance”. This counts even more if HV-values
above 100% are driven. Therefore note:
Always choose the lowest possible HV-value necessary to produce an
acceptable print result.
