19
KC-1800 · Revision 1.1
Chapter 5
Dip Switch Dip Switch Dip Switch Dip Switch Dip Switch
One set of dip switches is mounted in the control board of the KC-1800. To access these dip switches, please do
as follows:
• Turn off the printer
• Remove the paper from the mechanism
• Remove the screws that hold the cover of the control board
• Using the tables below, change the configuration of the dip switches
• Mount the cover of the control board and fasten the screws back
Dip Switch Function
1 Baud Rate On: 115200 bps
Off: 9600 bps *
2 PNE** On: activated
Off: not activated
3 Reserved Must be in off position
4 Stop Bits On: 1 stop bit *
Off: 2 stop bits
5 Character leght On: 7 bits
Off: 8 bits *
6 Parity Select On: Odd
Off: Even *
7 Parity On: not used *
Off: used
8 Presenter On: activated ***
Off: not activated ****
* Default
*** Default for printers with presenter
**** Default for printers without presenter
** ON - Default or :
After Esc m: PNE sensor is returned in status bit (serial or USB) or PE line (Parallel)
After Esc l: Presenter sensor is returned in status bit (serial or USB) or PE line (Parallel)
OFF - Default or after Esc m: always return paper ok
After Esc l: always return paper ok
