13
Electrical connection
The hood must be connected to the mains supply by qualified
and trained technicians.
The mains power supply must correspond to the rating
indicated on the plate situated inside the hood. If provided with
a plug connect the hood to a socket in compliance with current
regulations and positioned in an accessible area, after
installation. If it not fitted with a plug (direct mains connection)
or if the plug is not located in an accessible area, after
installation, apply a double pole switch in accordance with
standards which assures the complete disconnection of the
mains under conditions relating to over-current category III, in
accordance with installation instructions.
Warning! Before re-connecting the hood circuit to the mains
supply and checking the efficient function, always check that
the mains cable is correctly assembled.
Warning! Power cable replacement must be undertaken by
the authorised service assistance centre or similar qualified
person.
Mounting
Before starting to mount the appliance, make sure that no
component is damaged, otherwise contact the dealer and stop
mounting. In addition, read all the instructions below carefully.
Operation
Use the high suction speed in cases of concentrated kitchen
vapours. It is recommended that the cooker hood suction is
switched on for 5 minutes prior to cooking and to leave in
operation during cooking and for another 15 minutes
approximately after terminating cooking.
For the correct use please carefully read the intructions below.
Use of the remote control
the remote control can control all the functions of the hood:
Selection of the suction speeds (powers)
Control of the light
Key without functions
Reset and configuration of the filter saturation signal
Selection of the suction speeds (powers):
Press key "◄" or "►" until the following symbol is displayed
on the remote control: ”
Press key “+” or “-” or "■" respectively to increase or reduce or
switch off the suction speed (power).
The set suction speed is indicated by the LED in the suction
perimeter channel (Fig.9).
To each color generated by the LED, it corresponds a specific
speed, as shown below:
First speed WHITE
Second speed BLUE
Third speed DARK BLUE
Fourth speed RED
Light control:
Press key "◄" or "►" until the remote control displays the
symbol
The central light can be switched on and off in two ways:
1. Press key “+” or “-” respectively to switch on (ON) or off
(OFF) the central light.
2. Press key "■" to change the light state from off (OFF) to
on (ON) or viceversa.
Reset and configuration of the filter saturation signal
Switch on the hood at any speed (see paragraph above
“Selection of the suction speeds (powers)”)
Press key "◄" or "►" until the remote control displays the
symbol
Press keys “+” and “-“ contemporaneously for more than 3
seconds, all the suction speed LEDs (powers) stop flashing,
showing that the reset of the signal has been carried out.
Maintenance of the remote control
Cleaning the remote control:
Clean the remote control with a damp cloth and a neutral
solution of detergent without abrasive substances.
Changing the battery:
• Open the battery casing using a small screwdriver with a
flat point.
• Change the finished battery with a new one of 12 V type
MN21/23
In inserting the new battery respect the polarity indicated
on the battery casing!
• Close the battery casing up again.
Disposal of the batteries
Ultimate disposal of the batteries should be handled according
to all national laws and regulations. Do not place used
batteries in your regular waste. Ultimate disposal of the
batteries must be done safely . Contact your local waste
management officials for other information regarding the
environmentally sound collection, recycling, and disposal of
the batteries.
Operation anomalies
The hood does not work
Make sure that:
• There is no current blackout
• A speed has been effectively selected.
• The red reset button located above the filters inside the
hood is pressed.
The hood has low efficiency
Make sure that:
• The motor speed selected is sufficient for the quantity of
fumes present
• The kitchen is aired enough to allow an air intake and the
charcoal filter is not worn out (filter version hood).
• The air outlet pipe is not clogged.
