Installation – Flowserve NRGT26-1 User Manual

Page 15

Advertising
background image

5

1

Flange PN 40, DN 50 (2"), DIN 2527

Flange PN 40, DN 00 (4"), DIN 2527

2

For the approval of the boiler standpipe with connecting flange the relevant

regulations must be considered.

3

Vent hole

4

High water (HW)

5

Electrode rod d = 5 mm

6

Protection tube DN 80

7

Protection tube DN 00

8

Electrode distance ≥ 4 mm (LW)

9

Electrode distance ≥ 40 mm (LW)

0

Low water (LW)

!

Reducer K-88.9 x 3.2-42.4 x 2.6 W to DIN 266, part 2

"

Reducer K-4.3 x 3.6-48.3 x 2.9 W to DIN 266, part 2

Key

Installation

– continued –
