RAID 0 (Striped)
RAID 0 reads and writes sectors of data interleaved among multiple drives. If any disk
member fails, it affects the entire array. The disk array data capacity is equal to the
number of drive members times the capacity of the smallest member. RAID 0 does
not support fault tolerance.
RAID 1 (Mirror)
RAID 1 writes duplicate data onto a pair of drives and reads both sets of data in
parallel. If one of the mirrored drives suffers a mechanical failure or does not respond,
the remaining drive will continue to function. Due to redundancy, the drive capacity of
the array is the capacity of the smallest drive.
RAID Ready
A "RAID Ready" system is a specific system configuration that, with the addition of
a second Serial ATA hard drive, can be seamlessly migrated to a configuration that
provides either improved storage performance or data protection from a single hard
drive failure.
RAID 10 (Striped Mirror)
RAID 10 is a combination of striping and mirroring. This configuration provides optimal
speed and reliability, but you need four SATA hard disks.
Span (JboD)
JBOD stands for “Just a Bunch of Disks”. Each drive is accessed as if it were on a
standard SCSI host bus adapter. This is useful when a single drive configuration is
needed, but it offers no speed improvement or fault tolerance. A spanned volume is a
formatted partition which data is stored on more than one hard disk, yet appears as
one volume. Unlike RAID, spanned volumes have no fault-tolerance, so if any disk
fails, the data on the whole volume could be lost. Additionally, the system or boot
partitions cannot be included in a spanned volume. FAT16/32 and NTFS file systems
may be used, and the volume can span up to 32 hard disks.
Comparison Table :
Solution Hard Disks No. Capacity Performance Reliability Application
RAID0 >=2 All Highest Dangerous Look for speed
RAID1 2 50% Read faster Excellent 100% Data backup
RAID10 >=4 (Even number) Smallest*2 High Excellent Unlimited budget
Span >=1 All none Dangerous Big disk space
