1
FEATURES OF YOUR HYUNDAI
55
!
B290A03A-AAT
ENGINE COOLANT TEMPERATURE
GAUGE
WARNING:
Never remove the radiator cap when the
engine is hot. The engine coolant is under
pressure and could erupt and cause
severe burns. Wait until the engine is
cool before adding coolant to the
reservoir.
The normal range is approximately in the
middle between "H" and "C". If it moves
across the dial to "H" (HOT), pull over and
stop as soon as possible and turn off the
engine. Then open the hood and, after the
engine has cooled, check the coolant level
(See "If the engine overheats" on the page
3-4.) and the water pump drive belt. If you
suspect cooling system trouble, have your
cooling system checked by a Hyundai dealer
as soon as possible.
ONF048043N
INSTRUMENT CLUSTER
B280A01NF-AAT
FUEL GAUGE
The needle on the gauge indicates the
approximate fuel level in the fuel tank. The
fuel capacity is given in section 9.
NOTE:
The "
" symbol means, the fuel filler
lid is located on the left side of the ve-
hicle.
ONF048044N
