Chapter 5
Open the chassis
1.
Fig. 5-1 Loosen four screws on back to remove the
top lead. Keep the power cable locked on
rear panel.
Fig. 5-2 The top lead can be removed from the
base stand.
2.
Fig. 5-3 The base stand
Chapter 6
Removing and Installing CompactFlash Card
Fig. 6-1 Insert Compact Flash Card
Fig. 6-2 Push Compact Flash Card into the CF
interface
