INSTALLATION INSTRUCTIONS
Aqua-Scrubber
Placement
Carefully uncrate machine. Take caution not to
damage components which may be mounted on
the top or sides of the machine. Set unit in place
and adjust the bullet feet to level the machine.
Turning the bullet foot clockwise will lower the unit.
Turning the bullet foot counter-clockwise will raise
the unit.
Electrical Connections
Connect electrical lines sized for the correct
voltage, current and phase of the machine. These
should agree with the machine
requirements
indicated on the nameplate and labels on the con-
trol panel.
A single-point electrical connection is provided for
the pumps, control circuit, and wash tank heater.
PART 2 INSTALLATION INSTRUCTIONS
CAUTION:
Connections must be made to a circuit breaker
or fused disconnect as provided by the
end-user and required by local codes.
A laminated wiring diagram is inside the control panel.
Model
208-240VAC/10
Aqua-Scrubber
30A
Fuse Sizing Chart
Mechanical/Plumbing Connections
Connect hot (140ºF) water line and cold water line
to the provided faucet. Both are 3/4" connections.
Connect the drain line (1 ½”).
CAUTION:
Drain lines must be as specified on installation drawing.
Drain line must be properly vented and have fall of not
less than ¼” to the foot of proper flow. Some area
plumbing codes require drains to flow into an open gap
with an opening twice the diameter of the pipe.
Check with your local plumbing codes for the type of
drain connection required.
CAUTION:
Do not reduce the size of lines as specified
in installation drawings. All lines are sized to facilitate
necessary flows, pressures, etc.
CAUTION:
All lines must be flushed prior to use to remove debris.
For best washing results, use only Insinger
Aqua Wash detergent in the wash tank. Three pre-
packaged pouches have been provided with your
new Aqua Scrubber Warewashing System.
Open the Aqua Wash detergent pouch and dump
into the wash tank. One packet will last 2-4 hours,
depending on the soil load.
þ
NOTE:
Contact Insinger for our exclusive
AQUA WASH prepackaged detergent for
use in your Aqua Scrubber Warewashing
System. Toll-free, 800.344.4802 or on the
internet, [email protected]
Use any approved chlorine or iodine based food-
grade sanitizer in the sanitizing basin. Dilute to
manufacturers specifications. Consult your local
chemical supplier.
The unit should be regularly de-limed to avoid ex-
cessive limescale build-up in the tank and on com-
ponents. Any approved limescale removal chemical
