10.0 Orderable Part Numbers
 Hardware Development Kit (54-00016)
o QTY 1 MicroModule Demo with USB Cable
o QTY 5 Programmed Microchip PIC18F14K50 microprocessors 1
o QTY 5 4-Zone Mouse Sensor, Square
o QTY 5 4-Zone Mouse Sensor, Square with Conductive Adhesive
o QTY 5 4-Zone Mouse Sensor, Square with tail and solder tabs
2
o QTY 1 USB Flash Drive with Product Literature
 4 Zone Mouse Sensor and USB Interface Chip Datasheet
 4 Zone Mouse Sensor and USB Interface Chip Integration Guide
 Programmed Microprocessor, PIC18F14K50, Tape & Reel (54-00005)
 4-Zone Mouse Sensor, Square (34-00002)
 4-Zone Mouse Sensor, Square with Conductive Adhesive (30-79069)
 4-Zone USB High Temperature Microprocessor (24-00178)
11.0 Intellectual Property & Other Legal Matters
Interlink Electronics holds several domestic and international patents for its Force Sensing Resistor
technology. FSR and Force Sensing Resistor are company trademarks. All other trademarks are
the property of their respective owners.
The product information contained in this document provides general information and guidelines
only and must not be used as an implied contract with Interlink Electronics. Acknowledging our
policy of continual product development, we reserve the right to change, without notice, any detail
in this publication. Since Interlink Electronics has no control over the conditions and method of use
of our products, we suggest that any potential user confirm their suitability for their own application.
1
Microprocessors covered here are capable of measuring any of the 4 Zone FSR’s offered by
Interlink Electronics.
2
Sensors provided with tail extension and solder tabs for ease of connection during hardware
development.
