English–6
Bosch eBike Systems
0 276 001 SPI | (16.7.14)
450
Internal software error
Restart the system. If the problem persists, contact your Bosch eBike
dealer.
490
Internal error of the on-board
computer
Have the on-board computer checked
500
Internal error of the drive unit
Restart the system. If the problem persists, contact your Bosch eBike
dealer.
502
Bike lighting error
Check the light and the associated wiring. Restart the system. If the
problem persists, contact your Bosch eBike dealer.
503
Error of the speed sensor
Restart the system. If the problem persists, contact your Bosch eBike
dealer.
510
Internal sensor error
Restart the system. If the problem persists, contact your Bosch eBike
dealer.
511
Internal error of the drive unit
Restart the system. If the problem persists, contact your Bosch eBike
dealer.
530
Battery pack error
Switch off the eBike, remove the eBike battery pack and reinsert the
eBike battery pack. Restart the system. If the problem persists, contact
your Bosch eBike dealer.
531
Configuration error
Restart the system. If the problem persists, contact your Bosch eBike
dealer.
540
Temperature error
The eBike is outside of the permissible temperature range. Switch off the
eBike system and allow the drive unit to either cool down or heat up to
the permissible temperature. Restart the system. If the problem per-
sists, contact your Bosch eBike dealer.
550
An improper load was detected.
Remove load. Restart the system. If the problem persists, contact your
Bosch eBike dealer.
602
Internal battery pack error while
charging
Unplug the charger from the battery pack. Restart the eBike system. Plug
the charger into the battery pack. If the problem persists, contact your
Bosch eBike dealer.
602
Internal battery pack error
Restart the system. If the problem persists, contact your Bosch eBike
dealer.
603
Internal battery pack error
Restart the system. If the problem persists, contact your Bosch eBike
dealer.
605
Battery pack temperature error
The eBike is outside of the permissible temperature range. Switch off the
eBike system and allow the drive unit to either cool down or heat up to
the permissible temperature. Restart the system. If the problem per-
sists, contact your Bosch eBike dealer.
605
Battery pack temperature error while
charging
Unplug the charger from the battery pack. Allow the battery pack to cool.
If the problem persists, contact your Bosch eBike dealer.
606
External battery pack error
Check the wiring. Restart the system. If the problem persists, contact
your Bosch eBike dealer.
610
Battery pack voltage error
Restart the system. If the problem persists, contact your Bosch eBike
dealer.
620
Charging error
Replace the charger. Contact your Bosch eBike dealer.
640
Internal battery pack error
Restart the system. If the problem persists, contact your Bosch eBike
dealer.
655
Multiple battery pack errors
Switch off the eBike system. Remove the battery pack and reinsert it.
Restart the system. If the problem persists, contact your Bosch eBike
dealer.
Code
Cause
Corrective Measure
