Installing the Wall Mounting Plate
Remove all pieces of the wall mounting system to ensure
you have all necessary parts.
Be sure to choose a mounting location with easy
access to an AC power outlet.
Wood Stud Mounting:
Using an electronic stud sensor, locate at least three
1)
adjacent wall studs at least 12" apart.
With the help of a friend, align the wall plate’s top
2)
and bottom horizontal mounting slots over the center
of each wall stud.
LEVEL
CHECK
3)
Level the wall plate with the bubble level.
Hold the plate firmly in place.
Mark the stud center in each of the four slots
4)
(bottom left, top left, bottom right, top right).
With your electrical drill and 3/16" bit, pre-drill a 3"
5)
deep hole at each mark.
Attach the wall plate to the wall using the lag bolts
6)
and round washers as shown to the right. Tighten
each bolt with your electric drill or socket wrench.
Turn clockwise until secure.
