Hanging the TV and Vertical Adjustment
Bars on the Wall Plate
Monster strongly recommends that a minimum
of two people perform the following steps.
DO NOT release the TV until you are certain
it is properly mounted and secured to the
wall plate.
Connect the TV’s power cord and any AV cables to the
1)
TV before hanging it. With the help of a friend, lift the
TV and plug its power cord into a nearby AC outlet.
If routing AV cable in wall, route the cable through
the wall plate’s Pass-Thru slots into the prepared
opening in your wall.
Locate the two sets of
2)
QuickLift
™
hooks on the back of
the Vertical Adjustment Bars, now attached to your TV.
Hang either the upper or lower pair of
3)
QuickLift hooks
on the wall plate’s top and bottom horizontal channels.
(See diagram on opposite page.)
Secure the display with the L-Shaped Locking Bars.
4)
Slide them horizontally through the slot below either
bottom hook.
The locking bar should always be used to reduce
5)
the risk of seismic damage. A padlock can be added
for additional theft deterrence.
