Installing the Wall Plate
continued
Masonry Mounting
While masonry materials (bolts and concrete anchors)
are included, masonry mounting requires specialized
knowledge, skills and tools. Monster highly recommends
that you seek the assistance of a professional installer
when mounting to masonry.
DO NOT drill holes in masonry mortar joints.
LEVEL
CHECK
1)
With the help of a friend, position the wall
plate in your desired mounting location. Level the wall
plate with the provided bubble level. Mark the centers
of four bolt slots as shown to the right. Be careful not
to mark a mortar joint.
With your electrical drill and 1/2" masonry bit, pre-drill
2)
a 3" deep hole at each mark.
Install the supplied plastic concrete anchors in each
3)
hole. Tap into hole until fully seated.
Attach the wall plate to the wall using the lag bolts
4)
and round washers as shown to the right. Make
sure flat center of the plate is facing the wall.
