6. REAR PANEL AND INTERFACE INSTRUCTION
1. A-IN: Audio signal input
2. YPbPr: Component video signal input
3. V-IN: Composite video signal input
4. V-OUT: Composite video signal output
5. HDMI-IN:HDMI HD signal input
6. HDMI-OUT:HDMI HD signal output
7. 4 pin XLR DC power input interface
8. Power ON/OFF switch
9. The rear handle
7. POWER INPUT
Users can use this monitor with attached power adapter for power supply, can also use DC power
which output power is more than 20W for power supply
External power supply, please follow the picture XLR marked the correct access power.
