OWON AG1022 User Manual
Page 38
9.Technical Specifications
Waveform Characteristic
Sine
Flatness (when the Amplitude is 1.0
Vp-p (+4 dBm), relative to 1 kHz)
AG1022 1 μHz to 10 MHz:
0.2 dB ± 1mv
10 MHz to 25 MHz:
0.3 dB ± 1mv
AG1012 0.2 dB ± 1mv
Harmonic Distortion (when the
Amplitude is 1.0 Vp-p)
<-
40 dBc
Total Harmonic Distortion (when
the Amplitude is 1 Vp-p)
10 Hz to 20 kHz: <0.2 %
Phase Noise (when the Amplitude is
1 Vp-p)
-
110 dBc/Hz
Residue Clock Noise
-57 dBm (typical)
Square
Rise/Fall Time
<10ns (10%~90%) (typical, 1kHz, 1Vpp)
Jitter (rms)
6 ns + 30ppm
Non-symmetry (below 50% Duty
Cycle)
1% of period+ 5ns
Overshoot
< 5%
Duty Cycle
20% ~ 80% (< 1 MHz)
50% (1 MHz ~ 5 MHz)
Ramp
Linearity
< 0.1% of peak output (typical, 1kHz, 1Vpp,
Symmetry 50%)
Symmetry
0% to 100%
Pulse
Pulse Width
40 ns to 1000 ks
Accuracy
10ns
Rising/Falling Edge Time
< 10ns
Overshoot
< 5%
Jitter
6 ns + 30ppm
Arbitrary
Waveform Length
2 ~ 8K points
Sample Rate
125MSa/s
Amplitude Accuracy
14 bits
Minimum Rise/Fall Time
35ns (typical)
Jitter (RMS)
6 ns + 30ppm
Non-Volatile Storage
26 waveforms
Input/Output
Channel Coupling, Channel Copy
Phase Deviation
0 ~ 360°
Rear Panel
33
